BMW 8 series G14/G15 (2018-2022) driver's door automatic soft close drive unit Wiring diagram
This page shows the only wiring diagram for the component.driver's door automatic soft close drive unit, which is found in the car BMW 8 series G14/G15 (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's door automatic soft close drive unit (1 of 1)
ALL ROUND VISION CAMERA
BLU WIRE
BOOSTER
CENTER REAR PASSENGER'S SIDE DOOR TRIM PANEL LIGHTING
CONVERTIBLE TOP MODULE
COUPE CONVERTIBLE
DRIVER'S DOOR AUTOMATIC SOFT CLOSE DRIVE UNIT
DRIVER'S SIDE REAR ROLLER SUNBLIND SWITCH BLOCK
EXCEPT CONVERTIBLE
FRONT PASSENGER'S DOOR AUTOMATIC SOFT CLOSE DRIVE UNIT
FUSE 212
FUSE 214
FUSE 216
FUSE 220
FUSE 249
FUSE 251
FUSE 252
FUSE 254
FUSE 256
FUSE 257
FUSE 258
FUSE 259
FUSE 267
GRAN COUPE
GRN WIRE
HEAD UNIT
INTERFERENCE SUPPRESSION FILTER 2
LUGGAGE COMPARTMENT LAMP
PARKING MANEUVERING ASSISTANT
PASSENGER'S SIDE REAR ROLLER SUNBLIND SWITCH BLOCK
REAR DRIVER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE
REAR DRIVER'S SIDE SEAT HEATING MODULE
REAR PASSENGER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE
REAR PASSENGER'S SIDE DOOR POCKET LIGHTING
REAR PASSENGER'S SIDE SEAT HEATING MODULE
REAR VIEW CAMERA
RECEIVER AUDIO MODULE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR SPEAKER LIGHTING
SCR CONTROL UNIT
TAILGATE BUTTON ON INSIDE OF TRUNK LID
TRUNK COMPARTMENT LIGHT 2
TRUNK COMPARTMENT LIGHT TRUNK LID
W/ AUTOMATIC SOFT CLOSE SYSTEM
WIRELESS CHARGING SHELF ANTENNA AMPLIFIER
Go to component -> Power distribution circuit (7 of 8) -> DRIVER'S DOOR AUTOMATIC SOFT CLOSE DRIVE UNIT
