BMW 8 series G14/G15 (2018-2022) convertible coupe w/o automatic soft close system Wiring diagram
This page shows the only wiring diagram for the component.convertible coupe w/o automatic soft close system, which is found in the car BMW 8 series G14/G15 (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram convertible coupe w/o automatic soft close system (1 of 1)
BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
CENTRAL LOCKING BUTTON
CONVERTIBLE COUPE W/O AUTOMATIC SOFT CLOSE SYSTEM
DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS
DRIVER'S DOOR SWITCH BLOCK
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 249
FUSE 251
FUSE 264
FUSE 67
GRN WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/RED/YEL WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT W/ TERMINAL
INTERFERENCE SUPPRESSION FILTER
INTERFERENCE SUPPRESSION FILTER 2
NUMBER PLATE LIGHT W/ REAR LID BUTTON
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
TAILGATE BUTTON
TAILGATE BUTTON ON INSIDE OF TRUNK LID
TAILGATE LOCK
TRUNK LID LIGHT
TRUNK LID POWERTRAIN AUTOMATIC SOFT CLOSE SYSTEM
VEHICLE INTERIOR TAILGATE BUTTON
W/ AUTOMATIC LUGGAGE COMPARTMENT LID ACTUATION
W/ AUTOMATIC SOFT CLOSE SYSTEM
WHT/BLU WIRE
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Anti-theft & central locking circuit (3 of 3) -> CONVERTIBLE COUPE W/O AUTOMATIC SOFT CLOSE SYSTEM
