Sport seats circuit for BMW 8 series Gran Coupe G16 facelift (2022-2024)
Sport seats circuit
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
DRIVER'S SEAT PNEUMATIC PUMP
FRONT PASSENGER SEAT BACKREST WIDTH ADJUSTMENT VALVE BLOCK
FRONT PASSENGER SEAT PNEUMATIC PUMP
FUSE 64
FUSE 65
RED WIRE
RED/BRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
YEL/BLU WIRE
YEL/WHT WIRE
