Parking assistant circuit for BMW 8 series Gran Coupe G16 facelift (2022-2024)

BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE 252 GRN/BLK WIRE GRN/GRY WIRE HOT W/ LEFT FRONT CENTER ULTRASONIC SENSOR LEFT FRONT OUTER ULTRASONIC SENSOR LEFT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR ORG/ WIRE ORG/GRN WIRE ORG/YEL WIRE PARKING MANEUVERING ASSISTANT REAR POWER DISTRIBUTION BOX RED/GRN WIRE RELAY ENERGIZED RIGHT FRONT CENTER ULTRASONIC SENSOR RIGHT FRONT OUTER ULTRASONIC SENSOR RIGHT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR YEL/BLK WIRE YEL/GRY WIRE

BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/ORG WIRE BRN/RED WIRE BRN/VIO WIRE CENTER CONSOLE CONTROL CENTER COMPUTER DATA LINES SYSTEM FUSE 30 GRN/GRY WIRE HOT AT ALL TIMES LEFT REAR CENTER ULTRASONIC SENSOR LEFT REAR OUTER ULTRASONIC SENSOR LEFT REAR ULTRASONIC SENSOR ORG/ WIRE ORG/YEL WIRE PARKING ASSISTANCE BUTTON RED/GRY WIRE RIGHT FRONT POWER DISTRIBUTION BOX RIGHT REAR CENTER ULTRASONIC SENSOR RIGHT REAR OUTER ULTRASONIC SENSOR RIGHT REAR ULTRASONIC SENSOR VIO/WHT WIRE YEL/BLK WIRE
