Driver"s memory seat circuit for BMW 8 series Gran Coupe G16 facelift (2022-2024)

BLU/RED WIRE BODY DOMAIN CONTROLLER BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SEAT SWITCH CLUSTER DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE UNIT DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE UNIT DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE UNIT DRIVER'S SEAT MODULE FUSE 53 FUSE 67 GRY WIRE MEMORY FUNCTION HALL SENSOR NCA WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX SEATS SYSTEM SERVOMOTOR WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

BLU/BRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/YEL WIRE COUPE CONVERTIBLE DRIVER BACKREST LOCK SWITCH DRIVER'S SEAT BACKREST ANGLE ADJUSTMENT DRIVE DRIVER'S SEAT HEADREST HEIGHT ADJUSTMENT DRIVE DRIVER'S SEAT MODULE DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK GRY/BLK WIRE GRY/WHT WIRE MEMORY FUNCTION HALL SENSOR RED/BRN WIRE RED/YEL WIRE SEATS SYSTEM SERVOMOTOR WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/WHT WIRE
