BMW 8 series Gran Coupe G16 (2018-2022) Warning systems circuit
Warning systems circuit
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE 244
GRY/BLK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
LEFT FRONT ELECTRONIC WHEEL SYSTEM
LEFT REAR ELECTRONIC WHEEL SYSTEM
REAR POWER DISTRIBUTION BOX
RED WIRE
REMOTE CONTROL RECEIVER (LEFT CENTER OF REAR PACKAGE SHELF)
RIGHT FRONT ELECTRONIC WHEEL SYSTEM
RIGHT REAR WHEEL ELECTRONICS SYSTEM
