BMW 7 series G70 (2022-2024) tailgate soft-close motor Wiring diagram
This page shows the only wiring diagram for the component.tailgate soft-close motor, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate soft-close motor (1 of 1)
BASIC CENTRAL PLATFORM (BCP)
BLK/GRY WIRE
BLU/GRN WIRE
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
CENTRAL LOCKING BUTTON
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR CONTROL UNIT (TSGFA)
FUEL FILLER FLAP CENTRAL LOCKING DRIVE
FUSE 3
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
INSIDE TAILGATE BUTTON
LUGGAGE COMPARTMENT LAMP
OUTER TAILGATE BUTTON
RED/GRN WIRE
RED/WHT WIRE
TAILGATE BUTTON
TAILGATE LUGGAGE COMPARTMENT LIGHT
TAILGATE SOFT-CLOSE MOTOR
TRUNK LID LOCK
VEHICLE INTERIOR TAILGATE BUTTON
VIO/GRY WIRE
WHT/BLU WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Trunk & fuel door release circuit (2 of 2) -> TAILGATE SOFT-CLOSE MOTOR
