BMW 7 series G70 (2022-2024) steering column height adjustment motor Wiring diagram
This page shows the only wiring diagram for the component.steering column height adjustment motor, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column height adjustment motor (1 of 1)
BASIC CENTRAL PLATFORM (BCP)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRICAL STEERING COLUMN ADJUSTMENT
FUSE 166
FUSE 56
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/VIO WIRE
HOT W/
LEFT FRONT POWER DISTRIBUTION BOX
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
STEERING COLUMN ADJUSTMENT SWITCH
STEERING COLUMN EXTENSION ADJUSTMENT MOTOR
STEERING COLUMN HEIGHT ADJUSTMENT MOTOR
STEERING COLUMN SWITCH CLUSTER
WHT WIRE
WHT/BRN WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Steering column memory circuit -> STEERING COLUMN HEIGHT ADJUSTMENT MOTOR
