BMW 7 series G70 (2022-2024) rear driver's side automatic soft close system drive Wiring diagrams

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL LOCKING SYSTEM CONTROLLER DRIVE CENTRAL LOCKING SYSTEM MICROSWITCH COMPUTER DATA LINES SYSTEM DOOR CHECK CONTROLLER DRIVE END POSITION SWITCH FRONT PASSENGER DOOR LOCK GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/VIO WIRE LEFT "C" PILLAR) LOCKING POSITION 1 MICROSWITCH OPENING/ CLOSING CONTROLLER DRIVE REAR DRIVER'S SIDE AUTOMATIC SOFT CLOSE SYSTEM DRIVE REAR DRIVER'S SIDE DOOR CONTROL UNIT REAR PASSENGER'S SIDE DOOR DRIVE SERVOMOTOR RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE ROTARY STRIKER MICROSWITCH SOFT CLOSE AUTOMATIC DRIVE UNLOCKING, LOCKING CONTROLLER DRIVE VIO WIRE VIO/BLU WIRE VIO/YEL WIRE W/ CENTRAL LOCKING SYSTEM W/O CENTRAL LOCKING SYSTEM WHT WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/WHT WIRE BRN/YEL WIRE CENTRAL LOCKING SYSTEM CONTROLLER DRIVE CENTRAL LOCKING SYSTEM MICROSWITCH COMPUTER DATA LINES SYSTEM DOOR CHECK CONTROLLER DRIVE END POSITION SWITCH FRONT PASSENGER DOOR LOCK GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/VIO WIRE LEFT "C" PILLAR) LOCKING POSITION 1 MICROSWITCH OPENING/ CLOSING CONTROLLER DRIVE REAR DRIVER'S SIDE AUTOMATIC SOFT CLOSE SYSTEM DRIVE REAR DRIVER'S SIDE DOOR CONTROL UNIT REAR PASSENGER'S SIDE DOOR DRIVE SERVOMOTOR RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE ROTARY STRIKER MICROSWITCH SOFT CLOSE AUTOMATIC DRIVE UNLOCKING, LOCKING CONTROLLER DRIVE VIO WIRE VIO/BLU WIRE VIO/YEL WIRE W/ CENTRAL LOCKING SYSTEM W/O CENTRAL LOCKING SYSTEM WHT WIRE WHT/BRN WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE
