BMW 7 series G70 (2022-2024) passenger front seat backrest lighting 2 Wiring diagram
This page shows the only wiring diagram for the component.passenger front seat backrest lighting 2, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger front seat backrest lighting 2 (1 of 1)
BLU/WHT WIRE
BRN WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER DOOR DECORATIVE STRIP LIGHTING
FRONT PASSENGER DOOR MID-RANGE SPEAKER LIGHTING
FRONT PASSENGER DOOR TWEETER LIGHTING
FRONT PASSENGER SEAT BACKREST LIGHTING
GRN WIRE
GRY WIRE
GRY/VIO WIRE
LIGHT SOURCE 1
LIGHT SOURCE 10 LIGHT SOURCE 7
LIGHT SOURCE 11 LIGHT SOURCE 8
LIGHT SOURCE 12 LIGHT SOURCE 9
LIGHT SOURCE 2
LIGHT SOURCE 3
LIGHT SOURCE 6 LIGHT SOURCE 4
PASSENGER DOOR CONTROL UNIT
PASSENGER FRONT SEAT BACKREST LIGHTING 2
REAR PASSENGER SIDE DOOR CONTROL UNIT
REAR PASSENGER'S SIDE DOOR DECORATIVE STRIP LIGHTING
REAR PASSENGER'S SIDE DOOR SILL COURTESY LIGHT
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR FOOTWELL LIGHT
VIO WIRE
VIO/YEL WIRE
W/ HIGH END AUDIO
YEL/BLK WIRE
YEL/GRY WIRE
Go to component -> Courtesy lamps circuit (3 of 6) -> PASSENGER FRONT SEAT BACKREST LIGHTING 2
