BMW 7 series G70 (2022-2024) light source 9 Wiring diagram
This page shows the only wiring diagram for the component.light source 9, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light source 9 (1 of 1)
BASIC VERSION
BLU/GRN WIRE
BLU/WHT WIRE
DRIVER'S DOOR DECORATIVE STRIP LIGHTING
DYNAMIC STABILITY CONTROL (DSC)/ VIRTUAL INTEGRATION PLATFORM (VIP)
FRONT PASSENGER SEAT BACKREST LIGHTING
FRONT PASSENGER SEAT BACKREST LIGHTING 2
FRONT RADAR SENSOR (FRS)
FRONT RADAR SENSORS 3 4
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/BLU WIRE
GRY/VIO WIRE
LIGHT SOURCE 10
LIGHT SOURCE 11
LIGHT SOURCE 12
LIGHT SOURCE 13
LIGHT SOURCE 8
LIGHT SOURCE 9
PNK/RED WIRE
REAR LIGHT FOOTWELL LIGHT
REAR PASSENGER'S SIDE DOOR INSIDE HANDLE LIGHT
REAR PASSENGER'S SIDE DOOR POCKET LIGHTING
REAR RADAR SENSORS
RIGHT FRONT SIDE RADAR SENSOR SHORT RANGE (SRSNVR)
RIGHT REAR RADAR SENSOR SHORT RANGE (HRSNR)
VIO WIRE
VIO/YEL WIRE
W/ DRIVING ASSISTANT PROFESSIONAL
W/O DRIVING ASSISTANT PROFESSIONAL
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> High/low bus circuit (6 of 14) -> LIGHT SOURCE 9
