BMW 7 series G70 (2022-2024) left reading light touch control box Wiring diagram
This page shows the only wiring diagram for the component.left reading light touch control box, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left reading light touch control box (1 of 1)
AMBIENT LIGHT
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
FUSE 156
FUSE 168
FUSE 21
FUSE 23
FUSE 35
FUSE 63
FUSE 72
GRY WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/
INSTRUMENT CLUSTER LIGHTING
INTERIOR LIGHT)
INTERIOR LIGHTS TOUCH CONTROL BOX
LEFT FRONT POWER DISTRIBUTION BOX
LEFT READING LAMP BUTTON
LEFT READING LIGHT TOUCH CONTROL BOX
LIGHT SOURCE 1
LIGHT SOURCE 2
LIGHT SOURCE 5
LIGHT SOURCE 7
MENU INTERIOR LIGHTS TOUCH CONTROL BOX
PANORAMIC GLASS ROOF SKY LOUNGE TOUCH CONTROL BOX
PASSENGER'S SIDE CENTER CONSOLE LIGHTING
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY ENERGIZED
RIGHT FRONT CUP HOLDER LIGHTING
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT READING LAMP BUTTON
RIGHT READING LIGHT TOUCH CONTROL BOX
ROOF FUNCTION CENTER (FZD) (CENTER FRONT OF HEADLINER)
VIO/YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 6) -> LEFT READING LIGHT TOUCH CONTROL BOX
