BMW 7 series G70 (2022-2024) left front light electronics left headlight Wiring diagram
This page shows the only wiring diagram for the component.left front light electronics left headlight, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front light electronics left headlight (1 of 1)
BASIC CENTRAL PLATFORM (BCP) (RIGHT KICK PANEL)
BLK WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 28
FUSE 3
GEAR SELECTOR SWITCH
GRN WIRE
GRY/BLK WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
LEFT FRONT LIGHT ELECTRONICS LEFT HEADLIGHT
LEFT HEADLIGHT 2
PARKING BRAKE BUTTON
RADIATOR GRILLE LIGHTING
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
VIO/GRN WIRE
VIO/YEL WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Headlights circuit (1 of 2) -> LEFT FRONT LIGHT ELECTRONICS LEFT HEADLIGHT
