BMW 7 series G70 (2022-2024) left front door sill light strip Wiring diagrams
This page contains all the electrical diagrams for the component. left front door sill light strip, in which he is found in the car BMW 7 series G70 (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front door sill light strip (1 of 2)
BASIC CENTRAL PLATFORM (BCP)
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FUSE 20
FUSE 212
FUSE 22
FUSE 261
FUSE 272
FUSE 42
GRN WIRE
GRY WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/
LEFT FRONT DOOR SILL LIGHT STRIP
LEFT ILLUMINATED CARPET
LEFT PANORAMIC GLASS SUNROOF INTERIOR LIGHTING LIN SLAVE
LEFT PANORAMIC GLASS SUNROOF LED LIGHT INSERT
LEFT REAR DOOR SILL LIGHT STRIP
NCA WIRE
REAR CENTER ARMREST LIGHT
REAR INTERIOR LIGHT
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT DOOR SILL LIGHT STRIP
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT ILLUMINATED CARPET
RIGHT PANORAMIC GLASS SUNROOF INTERIOR LIGHTING LIN SLAVE
RIGHT PANORAMIC GLASS SUNROOF LED LIGHT INSERT
RIGHT REAR DOOR SILL LIGHT STRIP
VIO/YEL WIRE
WHT/GRN WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Courtesy lamps circuit (6 of 6) -> LEFT FRONT DOOR SILL LIGHT STRIP
