BMW 7 series G70 (2022-2024) intake air temperature sensor 2 Wiring diagram
This page shows the only wiring diagram for the component.intake air temperature sensor 2, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intake air temperature sensor 2 (1 of 1)
BLK WIRE
BLU WIRE
BOOST PRESSURE SENSOR
BRN WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL ENGINE ELECTRONICS
ENGINE OIL TEMPERATURE SENSOR
FUEL VENT VALVE
HEAT MANAGEMENT MODULE (LEFT REAR SIDE OF ENGINE)
INTAKE AIR TEMPERATURE SENSOR 2
INTAKE MANIFOLD PRESSURE SENSOR/CHARGE AIR TEMPERATURE
OIL PRESSURE CONTROL VALVE
POSITION SENSOR
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
VALVETRONIC SERVOMOTOR (TOP MIDDLE OF CYLINDER HEAD)
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.0l turbo (4 of 11) -> INTAKE AIR TEMPERATURE SENSOR 2
