BMW 7 series G70 (2022-2024) front passenger's backrest control electronics for active seat ventilation Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger's backrest control electronics for active seat ventilation, in which he is found in the car BMW 7 series G70 (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger's backrest control electronics for active seat ventilation (1 of 2)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S BACKREST CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
DRIVER'S SEAT CUSHION CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
DRIVER'S THIGH SUPPORT CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
EARLY PRODUCTION
FRONT PASSENGER'S BACKREST CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
FRONT PASSENGER'S SEAT CUSHION CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
FRONT PASSENGER'S THIGH SUPPORT CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
FUSE 277
FUSE 52
GRN/YEL WIRE
HOT W/ TERMINAL
LATE PRODUCTION
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLK WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
YEL WIRE
YEL/BLU WIRE
Go to component -> Front seat ventilation circuit -> FRONT PASSENGER'S BACKREST CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
Wiring diagram front passenger's backrest control electronics for active seat ventilation (2 of 2)
BMW THEATER SCREEN DRIVE 2
BOOSTER
BOTTOM RADIATOR BLIND DRIVE
CRASH SAFETY MODULE (ACSM)
ELECTRICAL MACHINE ELECTRONICS (EME)
FROM FUSE 44 (DIAGRAM 8 OF 11)
FRONT PASSENGER SEAT BACKREST LIGHTING
FRONT PASSENGER SEAT BACKREST LIGHTING 2
FRONT PASSENGER'S BACKREST CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
FRONT PASSENGER'S SEAT CUSHION CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
FRONT REMOTE CONTROL RECEIVER
FUSE 249
FUSE 250
FUSE 251
FUSE 252
FUSE 257
FUSE 270
FUSE 47
FUSE 49
FUSE 52
FUSE 54
FUSE 55
FUSE 56
FUSE 57
FUSE 59
FUSE 60
FUSE 62
FUSE 63
FUSE 64
FUSE 65
FUSE 69
FUSE 71
GRY/YEL WIRE
HIGH VOLTAGE BATTERY UNIT REFRIGERANT SHUTOFF VALVE
HIGH VOLTAGE BATTERY UNIT REFRIGERANT SHUTOFF VALVE 2
LEFT FRONT SIDE RADAR SENSOR SHORT RANGE (SRSNVL)
LEFT REAR REMOTE CONTROL RECEIVER
OIL MODULE
REAR REMOTE CONTROL RECEIVER AREA
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
REMOTE CONTROL RECEIVER
REMOTE CONTROL RECEIVER FOR CARGO
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT SIDE RADAR SENSOR SHORT RANGE (SRSNVL)
RIGHT REAR FOOTWELL LIGHT
RIGHT REAR REMOTE CONTROL RECEIVER
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY REEL
SELECTIVE CATALYTIC REDUCTION (SCR)
STEERING COLUMN SWITCH CLUSTER
TAILGATE FUNCTION MODULE (HKFM)
TANK FUNCTION ELECTRONICS (TFE)
TO FUSE 268 (DIAGRAM 10 OF 11)
TO FUSE 66 (DIAGRAM 11 OF 11)
TO REAR POWER DISTRIBUTION BOX (DIAGRAM (3 OF 11)
TO SAFETY BATTERY TERMINAL GAS GENERATOR (DIAGRAM (1 OF 11)
TOP RADIATOR BLIND DRIVE
VERTICAL DYNAMICS PLATFORM (VDP)
WASHER PUMPS CONTROL ELECTRONICS
WIPER MODULE
Go to component -> Power distribution circuit (5 of 11) -> FRONT PASSENGER'S BACKREST CONTROL ELECTRONICS FOR ACTIVE SEAT VENTILATION
