BMW 7 series G70 (2022-2024) front passenger power window drive Wiring diagram
This page shows the only wiring diagram for the component.front passenger power window drive, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger power window drive (1 of 1)
BLU WIRE
BLU/BRN WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER DOOR POWER WINDOW SWITCH
FRONT PASSENGER POWER WINDOW DRIVE
FUSE 223
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HOT W/
PASSENGER DOOR CONTROL UNIT
REAR PASSENGER SIDE DOOR CONTROL UNIT
REAR PASSENGER'S SIDE POWER WINDOW DRIVE
REAR PASSENGER'S SIDE POWER WINDOW SWITCH
REAR POWER DISTRIBUTION BOX
REAR WINDOW SOLAR SENSOR
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
W/ ROLLER SUNBLIND
W/O ROLLER SUNBLIND
WHT/BRN WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Power windows circuit (2 of 2) -> FRONT PASSENGER POWER WINDOW DRIVE
