BMW 7 series G70 (2022-2024) front passenger door drive servomotor Wiring diagrams

ANTI-THEFT ALARM SYSTEM LED BASIC CENTRAL PLATFORM (BCP) (RIGHT KICK PANEL) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DOOR CHECK CONTROLLER DRIVE ELECTROCHROMIC INTERIOR MIRROR FRONT PASSENGER DOOR DRIVE SERVOMOTOR FRONT PASSENGER DOOR INNER DOOR OPENING BUTTON FRONT PASSENGER DOOR TOUCH CONTROL PANEL FUSE 269 FUSE 270 FUSE 272 FUSE 32 FUSE 41 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE HOOD CONTACT SWITCH HOT AT ALL TIMES HOT W/ OPENING/ CLOSING CONTROLLER DRIVE REAR POWER DISTRIBUTION BOX RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX ROOF FUNCTION CENTER (FZD) SIREN W/ TILT ALARM SENSOR VIO/BLK WIRE VIO/BLU WIRE VIO/GRY WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE

ANTI-THEFT ALARM SYSTEM LED BASIC CENTRAL PLATFORM (BCP) (RIGHT KICK PANEL) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DOOR CHECK CONTROLLER DRIVE ELECTROCHROMIC INTERIOR MIRROR FRONT PASSENGER DOOR DRIVE SERVOMOTOR FRONT PASSENGER DOOR INNER DOOR OPENING BUTTON FRONT PASSENGER DOOR TOUCH CONTROL PANEL FUSE 269 FUSE 270 FUSE 272 FUSE 32 FUSE 41 GRN WIRE GRN/BLU WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE HOOD CONTACT SWITCH HOT AT ALL TIMES HOT W/ OPENING/ CLOSING CONTROLLER DRIVE REAR POWER DISTRIBUTION BOX RED WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX ROOF FUNCTION CENTER (FZD) SIREN W/ TILT ALARM SENSOR VIO/BLK WIRE VIO/BLU WIRE VIO/GRY WIRE WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE
