BMW 7 series G70 (2022-2024) front passenger belt force limiter gas generators Wiring diagram
This page shows the only wiring diagram for the component.front passenger belt force limiter gas generators, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger belt force limiter gas generators (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU/BRN WIRE
BRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/YEL WIRE
CENTER REAR SEAT BELT BUCKLE CONTACT
CENTER REAR SEAT OCCUPANCY DETECTION
DRIVER RETRACTOR TENSIONER
FRONT PASSENGER BELT FORCE LIMITER GAS GENERATORS
FRONT PASSENGER RETRACTOR TENSIONER
FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY/BLK WIRE
GRY/GRN WIRE
LEFT FRONT AIR BAG SENSOR
LEFT OUTER PEDESTRIAN PROTECTION SENSOR
LEFT REAR SEAT BELT BUCKLE CONTACT
NCA WIRE
ORG/ WIRE
RIGHT FRONT AIR BAG SENSOR
RIGHT FRONT PEDESTRIAN PROTECTION ACTUATOR
RIGHT HEAD AIR BAG GAS GENERATORS
RIGHT REAR SEAT BELT BUCKLE CONTACT
VIO WIRE
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
W/ REAR MULTI-FUNCTIONAL SEAT
W/O REAR MULTI-FUNCTIONAL SEAT
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Supplemental restraints circuit (2 of 5) -> FRONT PASSENGER BELT FORCE LIMITER GAS GENERATORS
