BMW 7 series G70 (2022-2024) front bumper comfort access antenna Wiring diagram
This page shows the only wiring diagram for the component.front bumper comfort access antenna, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front bumper comfort access antenna (1 of 1)
BASIC CENTRAL PLATFORM (BCP) (RIGHT KICK PANEL)
BLK WIRE
BRN WIRE
BRN/BLK WIRE
CARGO AREA REMOTE CONTROL RECEIVER
COMPUTER DATA LINES SYSTEM
DRIVER SIDE EXTERNAL ANTENNA
FRONT BUMPER COMFORT ACCESS ANTENNA
FRONT INTERIOR ANTENNA
FRONT REMOTE CONTROL RECEIVER
FUSE 270
FUSE 30
FUSE 4
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT FRONT REMOTE CONTROL RECEIVER
LEFT REAR REMOTE CONTROL RECEIVER
REAR BUMPER COMFORT ACCESS ANTENNA
REAR INTERIOR ANTENNA
REAR POWER DISTRIBUTION BOX
REAR REMOTE CONTROL RECEIVER
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
REMOTE CONTROL RECEIVER
RIGHT FRONT MICROWAVE SENSOR
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT REMOTE CONTROL RECEIVER
RIGHT REAR REMOTE CONTROL RECEIVER
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
Go to component -> Access/start circuit (1 of 2) -> FRONT BUMPER COMFORT ACCESS ANTENNA
