BMW 7 series G70 (2022-2024) front autonomous parking camera Wiring diagram
This page shows the only wiring diagram for the component.front autonomous parking camera, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front autonomous parking camera (1 of 1)
BLU/YEL WIRE
BRN/BLU WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
EARLY PRODUCTION
FRONT AUTONOMOUS PARKING CAMERA
GRN/GRY WIRE
GRY/GRN WIRE
LATE PRODUCTION
LEFT AUTONOMOUS PARKING CAMERA
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR OUTER ULTRASONIC SENSOR
LEFT REAR ULTRASONIC SENSOR
NCA WIRE
REAR AUTONOMOUS PARKING CAMERA
RED/BLU WIRE
RIGHT AUTONOMOUS PARKING CAMERA
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR OUTER ULTRASONIC SENSOR
RIGHT REAR ULTRASONIC SENSOR
WHT WIRE
YEL/BRN WIRE
Go to component -> Parking assistant circuit, w/ surround view camera (2 of 2) -> FRONT AUTONOMOUS PARKING CAMERA
