BMW 7 series G70 (2022-2024) driver's seat position sensor Wiring diagram
This page shows the only wiring diagram for the component.driver's seat position sensor, which is found in the car BMW 7 series G70 (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat position sensor (1 of 1)
BASIC CENTRAL PLATFORM (BCP)
BATTERY AUTOMATED DRIVING (BATTHAF)
BRN WIRE
BRN/YEL WIRE
CAN BUS TERMINAL RESISTOR
CENTER REAR SEAT BELT BUCKLE CONTACT
CENTER REAR SEAT OCCUPANCY DETECTION
COOLANT PUMP 4
CRASH SAFETY MODULE (ACSM)
DRIVER'S SEAT BELT BUCKLE CONTACT
DRIVER'S SEAT POSITION SENSOR
DYNAMIC STABILITY CONTROL (DSC)/VIRTUAL INTEGRATION PLATFORM (VIP)
ELECTRIC FAN
FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT
FRONT PASSENGER'S SEAT OCCUPANCY DETECTION
FRONT PASSENGER'S SEAT POSITION SENSOR
HAD BRAKE MODULE
INTELLIGENT BATTERY SENSOR
INTERFERENCE SUPPRESSION FILTER
LEFT REAR SEAT BELT BUCKLE CONTACT
LEFT REAR SEAT OCCUPANCY DETECTION
REAR CENTER ARMREST LIGHT
REAR CENTER CONSOLE ARMREST HEATING CONTROL ELECTRONICS
REAR PASSENGER SIDE DOOR CONTROL UNIT
REAR PASSENGER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
REAR SMARTPHONE TRAY MODULE (SAMH)
RIGHT END OF DASH)
RIGHT REAR DOOR OPERATING MODULE
RIGHT REAR OUTSIDE DOOR HANDLE LIGHT
RIGHT REAR SEAT BELT BUCKLE CONTACT
RIGHT REAR SEAT OCCUPANCY DETECTION
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
TANK FUNCTION ELECTRONICS (TFE)
TELEMATIC COMMUNICATION BOX (TCB)
USB CHARGING PORT 6
VERTICAL DYNAMICS PLATFORM
W/ REAR MULTI-FUNCTIONAL SEAT
W/O REAR MULTI-FUNCTIONAL SEAT
Go to component -> Ground distribution circuit (6 of 6) -> DRIVER'S SEAT POSITION SENSOR
