BMW 7 series G70 (2022-2024) coolant pump relay Wiring diagrams
This page contains all the electrical diagrams for the component. coolant pump relay, in which he is found in the car BMW 7 series G70 (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
coolant pump relay wiring diagram (1 of 5)
3.0L TURBO
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COOLANT EXPANSION TANK SHUTOFF VALVE
COOLANT PUMP RELAY
COOLANT TEMPERATURE SENSOR
CRANKCASE TEMPERATURE SENSOR
ELECTRIC FAN (BEHIND RADIATOR)
ELECTRIC FAN CUT-OFF RELAY
FUSE 126
FUSE 401
FUSE 64
FUSE 70
HEAT MANAGEMENT MODULE (3.0L TURBO) (LEFT REAR SIDE OF ENGINE)
HOT AT ALL TIMES
HOT W/
LEFT FRONT POWER DISTRIBUTION BOX
LOW TEMPERATURE COOLANT CIRCUIT SHUTOFF VALVE
RADIATOR OUTLET TEMPERATURE SENSOR
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT SIDE OF RADIATOR)
TEMPERATURE SENSOR
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Automatic a/c circuit (6 of 6) -> COOLANT PUMP RELAY
coolant pump relay wiring diagram (2 of 5)
3.0L TURBO
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COOLANT EXPANSION TANK SHUTOFF VALVE
COOLANT PUMP RELAY
COOLANT TEMPERATURE SENSOR
CRANKCASE TEMPERATURE SENSOR
ELECTRIC FAN (BEHIND RADIATOR)
ELECTRIC FAN CUT-OFF RELAY
FUSE 126
FUSE 401
FUSE 64
FUSE 70
HEAT MANAGEMENT MODULE (3.0L TURBO) (LEFT REAR SIDE OF ENGINE)
HOT AT ALL TIMES
HOT W/
LEFT FRONT POWER DISTRIBUTION BOX
LOW TEMPERATURE COOLANT CIRCUIT SHUTOFF VALVE
RADIATOR OUTLET TEMPERATURE SENSOR
RED WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT SIDE OF RADIATOR)
TEMPERATURE SENSOR
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Cooling fan circuit (2 of 2) -> COOLANT PUMP RELAY
coolant pump relay wiring diagram (3 of 5)
3.0L TURBO
4.0L TURBO HYBRID
AIR CONDITIONING COMPRESSOR
AUXILIARY HEATER COOLANT CHANGEOVER VALVE
AUXILIARY HEATER FUEL METERING PUMP
BOTTOM RADIATOR BLIND DRIVE
BRN WIRE
COOLANT PUMP 3
COOLANT PUMP 5
COOLANT PUMP RELAY
DIGITAL ENGINE ELECTRONICS
E-VANOS POWER ELECTRONICS
ELECTRICAL STEERING COLUMN ADJUSTMENT
FANFARE HORN
FANFARE HORN 2
FRONT ELECTRICAL ARS (EARSF)
FRONT RADAR SENSOR (FRS)
HEATING INSTRUMENT PANEL CONTROL ELECTRONICS
IGNITION COIL CYLINDER 1
IGNITION COIL CYLINDER 2
IGNITION COIL CYLINDER 3
IGNITION COIL CYLINDER 4
IGNITION COIL CYLINDER 5
IGNITION COIL CYLINDER 6
IGNITION COIL CYLINDER 7
IGNITION COIL, CYLINDER 8
INDEPENDENT AUXILIARY HEATER
INSTRUMENT CLUSTER LIGHTING
LEFT CENTER CLOSE RANGE SIDE RADAR SENSOR (SRSNML)
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT SIDE RADAR SHORT RANGE SENSOR (SRSNVL)
LEFT HEADLIGHT
LEFT ILLUMINATED CARPET
LONG RANGE FRONT RADAR SENSOR (FRSF)
NCA WIRE
RADIATOR GRILLE LIGHTING
RADOME HEATING
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT SIDE RADAR SHORT RANGE SENSOR (SRSNVR)
RIGHT HEADLIGHT
STEERING COLUMN SWITCH CLUSTER
TOP RADIATOR BLIND DRIVE
W/ REAR AXLE SLIP ANGLE CONTROL
WASHER PUMPS CONTROL ELECTRONICS
WIPER MODULE
Go to component -> Ground distribution circuit (2 of 6) -> COOLANT PUMP RELAY
coolant pump relay wiring diagram (4 of 5)
AUXILIARY CONTROL UNIT (SEC)
BATTERY AUTOMATED DRIVING (BATTHAF)
COOLANT PUMP RELAY
DISPLAY GROUP
DRIVER'S SIDE CENTER CONSOLE LIGHTING
ELECTRIC FAN
ELECTRIC FAN CUT OUT RELAY
ELECTRO- MECHANICAL POWER STEERING (EPS)
ELECTROCHROMIC INTERIOR MIRROR
FROM FUSE 62 (DIAGRAM 5 OF 11)
FRONT CENTER LIDAR CONTROL UNIT (LIDARVM)
FUSE 1043
FUSE 66
FUSE 67
FUSE 68
FUSE 70
FUSE 72
FUSE 900
FUSE 901
FUSE 902
FUSE 903
FUSE 908
FUSE 913
GLOVE BOX LIGHT SWITCH
HAD BRAKE MODULE
HEAD UNIT HIGH (HU-H)
HIGHLY AUTOMATED DRIVING POWER DISTRIBUTION BOX
INSTRUMENT CLUSTER LIGHTING
INSTRUMENT PANEL ON THE LEFT INTERIOR LIGHTING LIN SLAVE
INSTRUMENT PANEL ON THE RIGHT INTERIOR LIGHTING LIN SLAVE
INTERIOR TEMPERATURE SENSOR
LEFT FRONT CUP HOLDER LIGHTING
LEFT FRONT VANITY MIRROR LIGHT
LIDAR SENSOR
NCA WIRE
PASSENGER'S SIDE CENTER CONSOLE LIGHTING
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT CUP HOLDER LIGHTING
RIGHT FRONT FOOTWELL LIGHT
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT VANITY MIRROR LIGHT
Go to component -> Power distribution circuit (11 of 11) -> COOLANT PUMP RELAY
coolant pump relay wiring diagram (5 of 5)
BASIC CENTRAL PLATFORM (BCP)
BI-STABLE RELAY
BLK WIRE
COOLANT PUMP RELAY
DEADLOCKING RELAY
DIAGNOSTIC SOCKET
DRIVER TOUCH CONTROL BOX
DRIVER'S DOOR CONTROL UNIT (TSGFA)
DRIVER'S DOOR LOCKING RELAY
DUAL REMOTE CONTROL RECEIVER
DYNAMIC STABILITY CONTROL (DSC)/ VIRTUAL INTEGRATION PLATFORM (VIP)
EARLY PRODUCTION
ELECTRO- MECHANICAL POWER STEERING (EPS)
FROM FUSE 136 (DIAGRAM 3 OF 11)
FROM FUSE 401 (DIAGRAM 1 OF 11)
FROM RIGHT FRONT POWER DISTRIBUTION BOX (DIAGRAM 8 OF 11)
FUSE 1
FUSE 124
FUSE 126
FUSE 127
FUSE 134
FUSE 2
FUSE 3
FUSE 4
FUSE 400
FUSE 402
FUSE 403
FUSE 404
FUSE 5
FUSE 6
HEAD UNIT HIGH (HU-H)
INTEGRATED SUPPLY MODULE
LATE PRODUCTION
LEFT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
LOCKING RELAY
PASSENGER OUTSIDE DOOR HANDLE ELECTRONICS
RAIN/LIGHT/ SOLAR CONDENSATION SENSOR
REAR DRIVER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
REAR PASSENGER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
STEERING COLUMN SWITCH CLUSTER
TAILGATE FUNCTION MODULE (HKFM)
TELEMATIC COMMUNICATION BOX
TEMPERATURE SENSOR
TO LEFT FRONT POWER DISTRIBUTION BOX (DIAGRAM 3 OF 11)
TO RIGHT FRONT POWER DISTRIBUTION BOX (DIAGRAM 8 OF 11)
UNLOCKING RELAY
VERTICAL DYNAMICS PLATFORM (VDP)
Go to component -> Power distribution circuit (2 of 11) -> COOLANT PUMP RELAY
