BMW 7 series G11/G12 facelift (2019-2023) rear passenger's side seat adjustment switch cluster Wiring diagram
This page shows the only wiring diagram for the component.rear passenger's side seat adjustment switch cluster, which is found in the car BMW 7 series G11/G12 facelift (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear passenger's side seat adjustment switch cluster (1 of 1)
BLU/BRN WIRE
BLU/GRN WIRE
BRN WIRE
BRN/ORG WIRE
FUSE 263
GRN WIRE
REAR DRIVER'S SIDE LUMBAR SUPPORT PUMP
REAR DRIVER'S SIDE LUMBAR SUPPORT VALVE BLOCK
REAR DRIVER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
REAR PASSENGER'S SIDE LUMBAR SUPPORT PUMP
REAR PASSENGER'S SIDE LUMBAR SUPPORT VALVE BLOCK
REAR PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
REAR POWER DISTRIBUTION BOX
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
WHT/YEL WIRE
YEL/BLU WIRE
Go to component -> Rear lumbar circuit -> REAR PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER
