BMW 7 series G11/G12 facelift (2019-2023) gnd act seat pneumatics module pump Wiring diagram
This page shows the only wiring diagram for the component.gnd act seat pneumatics module pump, which is found in the car BMW 7 series G11/G12 facelift (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd act seat pneumatics module pump (1 of 1)
ACT SEAT PNEUMATICS MODULE PUMP SPLY SEAT PNEUMATICS MODULE PUMP
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/ORG WIRE
CAN BUS SIG
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
FUSE 263
FUSE 64
FUSE 65
GND ACT SEAT PNEUMATICS MODULE PUMP
HOT W/
HOT W/ TERMINAL
K CAN BUS
LEFT FRONT SEAT PNEUMATICS MODULE
LEFT FRONT SEAT PNEUMATICS MODULE PUMP
LEFT REAR SEAT PNEUMATICS MODULE
LEFT REAR SEAT PNEUMATICS MODULE PUMP
LR ACT PUMP
NCA WIRE
PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
PWR SPLY
REAR DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
REAR PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT SEAT PNEUMATICS MODULE
RIGHT FRONT SEAT PNEUMATICS MODULE PUMP
RIGHT REAR SEAT PNEUMATICS MODULE
RIGHT REAR SEAT PNEUMATICS MODULE PUMP
RR ACT PUMP
RR PUMP SPLY
SEAT ADJUSTMENT SW
SEAT ADJUSTMENT SW BLOCK
SEAT ADJUSTMENT SW BLOCK SHIELD
SHIELD
SPLY SEAT PNEUMATICS MODULE PUMP
SW SIG
WHT WIRE
WHT/YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Pneumatics seat circuit, w/ rear pneumatics seats (1 of 2) -> GND ACT SEAT PNEUMATICS MODULE PUMP
