BMW 7 series G11/G12 facelift (2019-2023) front passenger heating thigh support Wiring diagram
This page shows the only wiring diagram for the component.front passenger heating thigh support, which is found in the car BMW 7 series G11/G12 facelift (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger heating thigh support (1 of 1)
BLU/GRN WIRE
BLU/GRN/YEL WIRE
BLU/VIO WIRE
BLU/VIO/WHT WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
DRIVER'S SEAT BELT BUCKLE CONTACT
DYNAMIC STABILITY CONTROL (DSC)
FRONT PASSENGER HEATING THIGH SUPPORT
FRONT PASSENGER SEAT MODULE
FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS
FRONT PASSENGER SEAT OCCUPANCY DETECTION SEAT CUSHION HEATING/SENSOR
FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
NCA WIRE
PNK/BLU WIRE
PNK/WHT WIRE
REAR DRIVER'S SIDE SEAT BELT BUCKLE CONTACT
REAR PASSENGER'S SIDE BELT BUCKLE CONTACT
W/ EXTENDABLE THIGH SUPPORT
W/O EXTENDABLE THIGH SUPPORT
YEL/WHT WIRE
Go to component -> Supplemental restraints circuit (2 of 4) -> FRONT PASSENGER HEATING THIGH SUPPORT
