BMW 7 series G11/G12 facelift (2019-2023) front passenger active head restraint gas generator Wiring diagram
This page shows the only wiring diagram for the component.front passenger active head restraint gas generator, which is found in the car BMW 7 series G11/G12 facelift (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger active head restraint gas generator (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CRASH SAFETY MODULE (UNDER CENTER CONSOLE)
DRIVER ACTIVE HEAD RESTRAINT GAS GENERATOR
DRIVER BELT FORCE LIMITER GAS GENERATOR
DRIVER KNEE AIR BAG GAS GENERATOR
DRIVER RETRACTOR TENSIONER
DRIVER SIDE AIR BAG GAS GENERATOR
DRIVER'S AIR BAG GAS GENERATORS
FRONT PASSENGER ACTIVE HEAD RESTRAINT GAS GENERATOR
FRONT PASSENGER AIR BAG GAS GENERATORS
FRONT PASSENGER KNEE AIR BAG GAS GENERATOR
FRONT PASSENGER SIDE AIR BAG GAS GENERATOR
FUSE BOX
GRY/BLK WIRE
GRY/BRN WIRE
GRY/GRN WIRE
NCA WIRE
ORG/ WIRE
RED WIRE
STEERING COLUMN SWITCH CLUSTER
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraints circuit (4 of 4) -> FRONT PASSENGER ACTIVE HEAD RESTRAINT GAS GENERATOR
