Ground distribution circuit for BMW 7 series G11/G12 (2015-2019)

12 V CONNECTION 3 12 V CONNECTION 4 BLK WIRE BLOWER MOTOR W/ OUTPUT STAGE BODY DOMAIN CONTROLLER BRN WIRE CENTER FRONT PASSENGER DOOR TRIM PANEL LIGHTING CENTER REAR PASSENGER'S SIDE DOOR TRIM PANEL LIGHTING FRONT CIGARETTE LIGHTER 12 V CONNECTION FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS FRONT PASSENGER EXTERIOR MIRROR FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER SEAT BACKREST REAR PANEL LIGHTING FRONT PASSENGER SEAT MODULE FRONT PASSENGER SEAT PNEUMATIC PUMP FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER'S SIDE CONTROL ELECTRONICS ARMREST HEATING LEFT FRONT GLASS SUNROOF LIGHTING LEFT FRONT REAR GLASS SUNROOF LIGHTING LEFT REAR FRONT GLASS SUNROOF LIGHTING LEFT REAR GLASS SUNROOF LIGHTING NCA WIRE PANORAMA ROOF ROLLER BLIND DRIVE 2 PASSENGER ELECTRONIC OUTER DOOR HANDLE MODULE PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE PASSENGER'S DOOR ENTRANCE LIGHT PASSENGER'S DOOR POCKET LIGHTING PASSENGER'S DOOR SEAT SWITCH CLUSTER PASSENGER'S SIDE REAR LIGHT SABER PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS PASSENGER'S SIDE REAR ROLLER SUNBLIND SWITCH BLOCK REAR CIGARETTE LIGHTER 12 V CONNECTION REAR PASSENGER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR PASSENGER'S SIDE COURTESY LIGHTING REAR PASSENGER'S SIDE DOOR POCKET LIGHTING REAR PASSENGER'S SIDE DOOR SEAT SWITCH CLUSTER REAR PASSENGER'S SIDE ENTRY LIGHT REAR PASSENGER'S SIDE FOOTWELL LIGHT REAR PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE RIGHT "B" PILLAR VENTILATION GRILLE RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT GLASS SUNROOF LIGHTING RIGHT FRONT MID- RANGE SPEAKER LIGHTING RIGHT FRONT REAR GLASS SUNROOF LIGHTING RIGHT FRONT SEAT INFLATOR MODULE RIGHT FRONT TWEETER LIGHTING RIGHT ILLUMINATED CARPET RIGHT REAR FRONT GLASS SUNROOF LIGHTING RIGHT REAR GLASS SUNROOF LIGHTING RIGHT REAR SPEAKER LIGHTING RIGHT REVERSIBLE ELECTROMOTIVE AUTOMATIC REEL ROOF FUNCTION CENTER TOP FRONT PASSENGER DOOR TRIM PANEL LIGHTING TOP REAR PASSENGER DOOR TRIM PANEL LIGHTING W/ AUTOMATIC SOFT CLOSE SYSTEM W/ INTERIOR LIGHT PACKAGE

ACTIVE SOUND DESIGN AUXILIARY WATER PUMP BASE PLATE BLK/BRN WIRE BONNET CONTACT SWITCH BRAKE FLUID LEVEL SWITCH BRAKE LIGHT SWITCH BRN WIRE CAN TERMINATOR 2 CAN TERMINATOR 3 CAN TERMINATOR 4 CAN TERMINATOR 5 CAN TERMINATOR 6 CAN TERMINATOR 9 CENTER WASHER NOZZLE HEATER COOLANT LEVEL SENSOR DIAGNOSIS SOCKET EARLY PRODUCTION FRONT ELECTRIC AUXILIARY HEATER FRONT REFRIGERANT SHUT-OFF VALVE FUEL FILTER HEATING HEAD UNIT HEADLIGHT CLEANING SYSTEM WASHER PUMP HIFI AMPLIFIER INDEPENDENT AUXILIARY HEATER INDEPENDENT HEATING COOLANT CHANGEOVER VALVE INDEPENDENT HEATING FUEL METERING PUMP INFOTAINMENT FAN LEFT FRONT ENTRANCE LIGHT LEFT FRONT LANE CHANGE WARNING SLAVE LEFT HEADLIGHT LEFT REAR ENTRANCE LIGHT LEFT WASHER NOZZLE HEATER LIGHT EFFECT MANAGER NCA WIRE REAR SEAT ENTERTAINMENT REAR WINDOW DEFOGGER RIGHT END OF DASH) RIGHT FRONT LANE CHANGE WARNING SLAVE RIGHT WASHER NOZZLE HEATER TOP HIFI AMPLIFIER USB- HUB VIDEO MODULE WASHER FLUID LEVEL SENSOR WIPER MODULE WIRELESS CHARGING ODDMENTS TRAY AERIAL AMPLIFIER

12 V CONNECTION 2 BOOT LID/ TAILGATE LOCK BRN WIRE CENTER REAR DRIVER'S SIDE DOOR TRIM PANEL LIGHTING COMPRESSOR RELAY CRASH SAFETY MODULE DRIVER'S SEAT BELT BUCKLE CONTACT DRIVER'S SIDE REAR ENTRY LIGHT DRIVER'S SIDE REAR OUTER DOOR HANDLE ELECTRONIC MODULE DRIVER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS DRIVER'S SIDE REAR ROLLER SUNBLIND SWITCH BLOCK FRONT PASSENGER SEAT OCCUPANCY DETECTION EVALUATION ELECTRONICS FRONT PASSENGER'S SEAT BELT BUCKLE CONTACT LEFT "B" PILLAR VENTILATION GRILLE LEFT "C" PILLAR) LEFT ILLUMINATED CARPET LEFT INNER TAIL- LIGHT LEFT OUTER TAIL LIGHT LEFT REAR SPEAKER LIGHTING LICENSE PLATE LIGHT W/ REAR LID BUTTON NCA WIRE REAR AIR CONDITIONING SYSTEM BLOWER OUTPUT STAGE REAR CENTER SEAT BELT BUCKLE CONTACT REAR COMPARTMENT AIR CONDITIONING SYSTEM REAR DRIVER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR DRIVER'S SIDE CONTROL ELECTRONICS ARMREST HEATING REAR DRIVER'S SIDE COURTESY LIGHTING REAR DRIVER'S SIDE DOOR POCKET LIGHTING REAR DRIVER'S SIDE DOOR SEAT SWITCH CLUSTER REAR DRIVER'S SIDE LIGHT SABER REAR DRIVER'S SIDE SEAT BELT BUCKLE CONTACT REAR PASSENGER'S SIDE SEAT BELT BUCKLE CONTACT REAR POWER DISTRIBUTION BOX REAR REFRIGERANT SHUT-OFF VALVE RIGHT INNER TAIL LIGHT RIGHT OUTER TAIL LIGHT SCR CONTROL UNIT SIREN W/ TILT ALARM SENSOR TOP REAR DRIVER'S SIDE DOOR TRIM PANEL LIGHTING TRAILER MODULE TRAILER SOCKET VERTICAL DYNAMICS PLATFORM W/ INTERIOR LIGHT PACKAGE W/ REAR COMFORT SEAT W/O REAR COMFORT SEAT WIRELESS CHARGING ODDMENTS TRAY

BLK WIRE BRN WIRE CENTER DRIVER'S DOOR TRIM PANEL LIGHTING DIAGNOSIS SOCKET DRIVER ELECTRONIC OUTER DOOR HANDLE MODULE DRIVER EXTERIOR MIRROR DRIVER LUMBAR SUPPORT VALVE BLOCK DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE DRIVER'S DOOR ENTRANCE LIGHT DRIVER'S DOOR POCKET LIGHTING DRIVER'S DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS DRIVER'S DOOR SEAT SWITCH CLUSTER DRIVER'S DOOR SWITCH BLOCK DRIVER'S SEAT BACKREST REAR PANEL LIGHTING DRIVER'S SEAT MODULE DRIVER'S SEAT PNEUMATIC PUMP DRIVER'S SIDE CONTROL ELECTRONICS ARMREST HEATING DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK ELECTRICAL EXHAUST FLAP FRONT CENTER ARMREST LIGHT GEAR SELECTOR SWITCH INTERIOR REAR LID BUTTON LEFT FRONT FOOTWELL LIGHT LEFT FRONT LIGHTING TWEETER LEFT FRONT MID- RANGE SPEAKER LIGHTING LEFT FRONT SEAT INFLATOR MODULE LEFT REAR SEAT INFLATOR MODULE LEFT REVERSIBLE ELECTROMOTIVE AUTOMATIC REEL NATURAL VACUUM LEAK DETECTION NOISE SUPPRESSOR FILTER OPTIONAL EXTRA SYSTEM PREMIUM TOP HIFI AMPLIFIER PRESSURIZED FUEL TANK CONTROL MODULE REAR COMPARTMENT FAN MOTOR OUTPUT STAGE REAR DRIVER'S SIDE FOOTWELL LIGHT REAR DRIVER'S SIDE LUMBAR SUPPORT PUMP REAR DRIVER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR DRIVER'S SIDE SEAT HEATING MODULE REAR DRIVER'S SIDE SEAT MODULE REAR PASSENGER'S SIDE CONTROL ELECTRONICS ARMREST HEATING REAR PASSENGER'S SIDE LUMBAR SUPPORT PUMP REAR PASSENGER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR PASSENGER'S SIDE SEAT HEATING MODULE REAR PASSENGER'S SIDE SEAT MODULE RIGHT REAR COMPARTMENT AIR CONDITIONING CONTROL PANEL RIGHT REAR SEAT INFLATOR MODULE TELEMATIC COMMUNICATION BOX TOP DRIVER'S DOOR TRIM PANEL LIGHTING W/ INTERIOR LIGHT PACKAGE

AUC SENSOR AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY AUXILIARY BATTERY CHARGING CONTROLLER BRN WIRE BRN/BLK WIRE CAMERA-BASED DRIVER ASSISTANCE SYSTEMS CENTER CONSOLE CONTROL PANEL CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS CONTROLLER COOLER BOX CUT-OFF RELAY ELECTRICAL EXHAUST FLAP 2 ELECTROCHROMIC INTERIOR REAR VIEW MIRROR ELECTRONIC NIGHT VISION MODULE LEFT FRONT VANITY MIRROR SWITCH LEFT REAR INTERIOR LIGHT LEFT REAR SEAT HEATING SWITCH LEFT REAR SLAVE LANE CHANGE WARNING LEFT REAR VANITY MIRROR LIGHT NCA WIRE PARKING ASSISTANT PARKING BRAKE BUTTON POWER CONTROL UNIT RAIN/LIGHT/ SOLAR CONDENSATION SENSOR REAR BASE PLATE REAR BASE PLATE 2 REAR CENTER ARMREST LIGHT REAR CONSOLE CAPTAIN'S CHAIR LIGHTING REAR CONSOLE CAPTAIN'S CHAIR LIGHTING 2 REAR DRIVER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER REAR INTERIOR LIGHT REAR PASSENGER'S SIDE SEAT ADJUSTMENT SWITCH CLUSTER REMOTE CONTROL RECEIVER REVERSING CAMERA RIGHT FRONT VANITY MIRROR SWITCH RIGHT REAR ENTRANCE LIGHT RIGHT REAR INTERIOR LIGHT RIGHT REAR MASTER LANE CHANGE WARNING RIGHT REAR SEAT HEATING SWITCH RIGHT REAR VANITY MIRROR LIGHT ROOF FUNCTION CENTER TAILGATE FUNCTION MODULE TOUCH COMMAND SNAP-IN ADAPTER W/ OPTIONAL EXTRAS W/O OPTIONAL EXTRAS W/ PANORAMIC ROOF W/O 4-ZONE AIR CONDITIONING W/O PANORAMIC ROOF

3.0L TURBO 3.0L TURBO 4.4L TURBO 4.4L TURBO A/C COMPRESSOR ACTIVE CRUISE CONTROL AIR FRESHENER AIR SUPPLY SYSTEM BLK WIRE BODY DOMAIN CONTROLLER BOTTOM RADIATOR BLIND DRIVE BRN WIRE CHARGE AIR COOLER COOLANT PUMP DIGITAL MOTOR ELECTRONICS DIGITAL MOTOR ELECTRONICS 2 DYNAMIC STABILITY CONTROL (DSC) ELECTRIC FAN ELECTRIC FUEL PUMP CONTROL ELECTRONICS ELECTRIC STEERING COLUMN ADJUSTMENT ELECTROMECHANICAL POWER STEERING ELECTRONIC TRANSMISSION CONTROL FRONT ELECTRIC ACTIVE ROLL STABILIZATION FRONT POWER DISTRIBUTION BOX HIGH RANGE HORN IGNITION COIL CYLINDER 1 IGNITION COIL CYLINDER 2 IGNITION COIL CYLINDER 3 IGNITION COIL CYLINDER 4 IGNITION COIL CYLINDER 5 IGNITION COIL CYLINDER 6 IGNITION COIL CYLINDER 7 IGNITION COIL, CYLINDER 8 INSTRUMENT PANEL SPEAKER LIGHTING IONIZER LEFT FOG LIGHT LOW RANGE HORN NCA WIRE REAR AXLE KING PIN INCLINATION CONTROL REAR ELECTRIC ACTIVE ROLL STABILIZATION RIGHT FOG LIGHT RIGHT HEADLIGHT STEERING COLUMN SWITCH CLUSTER TOP RADIATOR BLIND DRIVE TRANSFER BOX TURBOCHARGER COOLANT PUMP
