BMW 7 series G11/G12 (2015-2019) gesture recognition camera Wiring diagram
This page shows the only wiring diagram for the component.gesture recognition camera, which is found in the car BMW 7 series G11/G12 (2015-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gesture recognition camera (1 of 1)
ALL ROUND VISION CAMERA (LEFT END OF DASH)
BLK/BRN WIRE
BLK/RED WIRE
BLU/BRN WIRE
BLU/RED WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/BLK WIRE
CENTER CONSOLE CONTROL PANEL
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR MIRROR
EXTERIOR MIRROR CAMERA
FRONT CAMERA
FRONT PASSENGER MIRROR
FUSE 262
FUSE 32
FUSE 46
GESTURE RECOGNITION CAMERA
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY/BRN WIRE
GRY/RED WIRE
HEAD UNIT
HOT AT ALL TIMES
HOT W/
NCA WIRE
ORG/GRN WIRE
ORG/YEL WIRE
PARKING ASSISTANT
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLU WIRE
RED/WHT WIRE
RELAY ENERGIZED
REVERSING CAMERA
RIGHT END OF DASH)
RIGHT FRONT POWER DISTRIBUTION
ROOF FUNCTION CENTER
VIO/WHT WIRE
VIO/WHT/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> All around vision camera circuit -> GESTURE RECOGNITION CAMERA
