BMW 7 series G11/G12 (2015-2019) front passenger side seat adjustment switch block Wiring diagrams

BRN WIRE BRN/ORG WIRE DRIVER'S LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEAT PNEUMATIC PUMP DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER'S LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER'S SEAT PNEUMATIC PUMP FUSE 64 FUSE 65 RED WIRE RED/BLK WIRE RELAY ENERGIZED RIGHT END OF DASH) RIGHT FRONT POWER DISTRIBUTION BOX WHT/RED WIRE WHT/YEL WIRE

12 V CONNECTION 3 12 V CONNECTION 4 BLK WIRE BLOWER MOTOR W/ OUTPUT STAGE BODY DOMAIN CONTROLLER BRN WIRE CENTER FRONT PASSENGER DOOR TRIM PANEL LIGHTING CENTER REAR PASSENGER'S SIDE DOOR TRIM PANEL LIGHTING FRONT CIGARETTE LIGHTER 12 V CONNECTION FRONT PASSENGER DOOR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS FRONT PASSENGER EXTERIOR MIRROR FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER SEAT BACKREST REAR PANEL LIGHTING FRONT PASSENGER SEAT MODULE FRONT PASSENGER SEAT PNEUMATIC PUMP FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER'S SIDE CONTROL ELECTRONICS ARMREST HEATING LEFT FRONT GLASS SUNROOF LIGHTING LEFT FRONT REAR GLASS SUNROOF LIGHTING LEFT REAR FRONT GLASS SUNROOF LIGHTING LEFT REAR GLASS SUNROOF LIGHTING NCA WIRE PANORAMA ROOF ROLLER BLIND DRIVE 2 PASSENGER ELECTRONIC OUTER DOOR HANDLE MODULE PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE PASSENGER'S DOOR ENTRANCE LIGHT PASSENGER'S DOOR POCKET LIGHTING PASSENGER'S DOOR SEAT SWITCH CLUSTER PASSENGER'S SIDE REAR LIGHT SABER PASSENGER'S SIDE REAR POWER WINDOW DRIVE W/ CONTROL ELECTRONICS PASSENGER'S SIDE REAR ROLLER SUNBLIND SWITCH BLOCK REAR CIGARETTE LIGHTER 12 V CONNECTION REAR PASSENGER'S SIDE AUTOMATIC SOFT-CLOSE DRIVE REAR PASSENGER'S SIDE COURTESY LIGHTING REAR PASSENGER'S SIDE DOOR POCKET LIGHTING REAR PASSENGER'S SIDE DOOR SEAT SWITCH CLUSTER REAR PASSENGER'S SIDE ENTRY LIGHT REAR PASSENGER'S SIDE FOOTWELL LIGHT REAR PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE RIGHT "B" PILLAR VENTILATION GRILLE RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT GLASS SUNROOF LIGHTING RIGHT FRONT MID- RANGE SPEAKER LIGHTING RIGHT FRONT REAR GLASS SUNROOF LIGHTING RIGHT FRONT SEAT INFLATOR MODULE RIGHT FRONT TWEETER LIGHTING RIGHT ILLUMINATED CARPET RIGHT REAR FRONT GLASS SUNROOF LIGHTING RIGHT REAR GLASS SUNROOF LIGHTING RIGHT REAR SPEAKER LIGHTING RIGHT REVERSIBLE ELECTROMOTIVE AUTOMATIC REEL ROOF FUNCTION CENTER TOP FRONT PASSENGER DOOR TRIM PANEL LIGHTING TOP REAR PASSENGER DOOR TRIM PANEL LIGHTING W/ AUTOMATIC SOFT CLOSE SYSTEM W/ INTERIOR LIGHT PACKAGE

BOTTOM CENTER INSTRUMENT PANEL LIGHTING BOTTOM DRIVER'S SIDE INSTRUMENT PANEL LIGHTING BOTTOM FRONT PASSENGER'S SIDE INSTRUMENT PANEL LIGHTING CENTER DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING DRIVER'S LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEAT BACKREST REAR PANEL LIGHTING DRIVER'S SIDE INSTRUMENT PANEL LIGHTING DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FROM FUSE 49 (DIAGRAM 3 OF 8) FRONT GLASS SUNROOF LIGHTING (LEFT FRONT) FRONT GLASS SUNROOF LIGHTING (LEFT REAR) FRONT GLASS SUNROOF LIGHTING (RIGHT FRONT) FRONT GLASS SUNROOF LIGHTING (RIGHT REAR) FRONT PASSENGER LUMBAR SUPPORT VALVE BLOCK FRONT PASSENGER SEAT BACKREST REAR PANEL LIGHTING FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FUSE 60 FUSE 62 FUSE 64 FUSE 65 FUSE 66 LEFT FRONT FOOTWELL LIGHT LEFT FRONT SEAT INFLATOR MODULE LEFT FRONT VANITY MIRROR LIGHT LEFT REAR INTERIOR LIGHT LEFT REAR SPEAKER LIGHTING LEFT REAR VANITY MIRROR LIGHT REAR DRIVER'S SIDE DOOR POCKET LIGHTING REAR DRIVER'S SIDE DOOR SEAT SWITCH CLUSTER REAR DRIVER'S SIDE FOOTWELL LIGHT REAR DRIVER'S SIDE LIGHT SABER REAR GLASS SUNROOF LIGHTING (LEFT FRONT) REAR GLASS SUNROOF LIGHTING (LEFT REAR) REAR GLASS SUNROOF LIGHTING (RIGHT FRONT) REAR GLASS SUNROOF LIGHTING (RIGHT REAR) REAR INTERIOR LIGHT REAR PASSENGER'S SIDE FOOTWELL LIGHT RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT SEAT INFLATOR MODULE RIGHT FRONT VANITY MIRROR LIGHT RIGHT REAR COMPARTMENT AIR CONDITIONING CONTROL PANEL RIGHT REAR INTERIOR LIGHT RIGHT REAR VANITY MIRROR LIGHT TO FUSE 67 (DIAGRAM 5 OF 8) TOP CENTER DASHBOARD LIGHTING TOP FRONT PASSENGER'S SIDE INSTRUMENT PANEL LIGHTING TOP REAR DRIVER'S SIDE DOOR TRIM PANEL LIGHTING W/ INTERIOR LIGHT PACKAGE W/ MULTI- FUNCTION SEAT W/ PANORAMIC ROOF W/O PANORAMIC ROOF
