BMW 7 series F01/F02 facelift (2012-2015) central gateway module Wiring diagrams
This page contains all the electrical diagrams for the component. central gateway module, in which he is found in the car BMW 7 series F01/F02 facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram central gateway module (1 of 2)
ACTIVE TANK FUEL DOSING LEVEL LINE SENSOR HEATING
AUC SENSOR
BASIC VARIANT ROOF FUNCTIONS MODULE
BOOT LID LEFT INNER TAILGATE TAIL LIGHT LOCK
BOOT LID LIFT
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
CAMERA-BASED DRIVER ASSISTANCE SYSTEMS
CENTER CONSOLE
CENTER CONSOLE CONTROL PANEL
CENTER REAR BUCKLE CONTACT
CENTRAL GATEWAY MODULE
CRASH SAFETY MODULE
DIAGNOSIS PLUG
DRIVER'S SEAT BELT BUCKLE CONTACT
EARLY PRODUCTION LATE PRODUCTION
ELECTROCHROMIC INTERIOR REAR VIEW MIRROR
ELECTRONIC RIDE HEIGHT AIR SUPPLY CONTROL SYSTEM
FOOTWELL MODULE
HIGH VARIANT ROOF FUNCTIONS MODULE
HOTEL POSITION SWITCH
INTEGRATED CHASSIS MANAGEMENT
LANE DEPARTURE WARNING
LEFT FRONT VANITY MIRROR SWITCH
LEFT REAR VANITY MIRROR LIGHT
LICENSE PLATE LIGHT SCR W/ REAR CONTROL LID BUTTON UNIT
NCA WIRE
PARKING BRAKE CONTROL UNIT
PARKING COMPRESSOR BRAKE RELAY BUTTON
PASSENGER'S SEAT BELT BUCKLE CONTACT
PASSENGER'S SEAT OCCUPANCY DETECTION
REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL
REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL CONTROLLER
REAR COMPARTMENT PARKING DISPLAY 2 ASSISTANT
REAR DRIVER'S SIDE SEAT BELT BUCKLE CONTACT
REAR PASSENGER'S SIDE SEAT BELT BUCKLE CONTACT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT INNER TAIL LIGHT
RIGHT REAR VANITY MIRROR LIGHT
SIREN FUEL PUMP W/ TILT CONTROL ALARM (EKPS) SENSOR
W/ BASIC VARIANT
W/ HIGH VARIANT
WASHER FLUID LEVEL BOOT LID SWITCH LIFT
Go to component -> Ground distribution circuit (4 of 7) -> CENTRAL GATEWAY MODULE
Wiring diagram central gateway module (2 of 2)
BRN WIRE
BRN/BLK WIRE
CENTRAL GATEWAY MODULE
CLIMATE CONTROL
COMPUTER DATA LINES SYSTEM
ELECTRONICS JUNCTION BOX
FUSE
FUSE 187 FUSE HOLDER (RIGHT FRONT OF ENGINE COMPT)
FUSE 188
GRN WIRE
HEATING SWITCH (W/O REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL)
JUNCTION BOX (RIGHT SIDE OF DASH)
NCA WIRE
ORG/GRN WIRE
REAR
REAR COMPARTMENT AUTOMATIC
REAR DRIVER'S SIDE SEAT BACKREST HEATING ELEMENT
REAR DRIVER'S SIDE SEAT CUSHION HEATING ELEMENT
REAR DRIVER'S SIDE SEAT HEATING MODULE (LEFT SIDE OF LEFT REAR SEAT BACK)
REAR DRIVER'S SIDE SEAT HEATING SWITCH
REAR PASSENGER'S SIDE SEAT
REAR PASSENGER'S SIDE SEAT BACKREST HEATING ELEMENT
REAR PASSENGER'S SIDE SEAT CUSHION HEATING ELEMENT
REAR PASSENGER'S SIDE SEAT HEATING MODULE (RIGHT SIDE OF RIGHT REAR SEAT BACK)
RED/BRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY ENERGIZED
W/O REAR COMPARTMENT AUTOMATIC CLIMATE CONTROL
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component -> Rear heated seats circuit, without memory -> CENTRAL GATEWAY MODULE
