Car Wiring Diagrams for Charging circuit for BMW 7 series F01/F02 (2008-2012)

4.4L TWIN TURBO 6.0L TURBO ALTERNATOR BATTERY BLU WIRE COMPUTER DATA LINES SYSTEM DIGITAL MOTOR ELECTRONICS (RIGHT FRONT OF ENGINE COMPT) FUSE 500 N/A FUSE BOX (CENTER OF LUGGAGE COMPT) GRN/RED WIRE INTELLIGENT BATTERY SENSOR (UNDER CENTER OF LUGGAGE COMPT) JUMPER START TERMINAL POINT (RIGHT SIDE OF ENGINE COMPT) NCA WIRE OIL CONDITION SENSOR (LOWER RIGHT REAR OF ENGINE) POWER DISTRIBUTION SYSTEM RADIATOR SHUTTER DRIVE UNIT RED WIRE SAFETY BATTERY TERMINAL GENERATOR (CENTER OF LUGGAGE COMPT) STARTER MOTOR TRANSFER TERMINAL POINT VIO WIRE
