Memory mirrors circuit, with lin bus function for BMW 7 series F01/F02 (2008-2012)
Memory mirrors circuit, with lin bus function
23 22 BUS SIG BUS SIG
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SIDE OUTSIDE
FOOTWELL MODULE (LEFT KICK PANEL)
FUSE 32
JUNCTION BOX (RIGHT SIDE OF DASH)
MIRROR
NCA WIRE
PASSENGER'S SIDE OUTSIDE MIRROR
RED/GRY WIRE
RELAY ENERGIZED
WHT/BRN WIRE
WHT/BRN/YEL WIRE
