BMW 7 series F01/F02 (2008-2012) high variant roof function Wiring diagram
This page shows the only wiring diagram for the component.high variant roof function, which is found in the car BMW 7 series F01/F02 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high variant roof function (1 of 1)
BASIC VARIANT ROOF FUNCTION
BLK/BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
DAYLIGHT SIDE LIGHTS/
DRIVING LIGHT
FUSE 66
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRY/VIO WIRE
HEADLIGHT DRIVER MODULE
HEADLIGHT RANGE CONTROL DRIVE UNIT
HIGH VARIANT ROOF FUNCTION
HOT W/
JUNCTION BOX (RIGHT SIDE OF DASH)
LAMP BLUB XENON
LIGHT SWITCH UNIT
MODULE (CENTER FRONT OF ROOF)
RAIN/DRIVING LIGHTS/ CONDENSATION /SOLAR SENSOR
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT HEADLIGHT
SHUTTER BI-XENON
SWIVEL MODULE (W/ ADAPTIVE HEADLIGHT)
W/ BASIC VARIANT
W/ BASIC W/ HIGH VARIANT VARIANT
W/ HIGH VARIANT
WHT/GRN WIRE
XENON CONTROL UNIT
YEL/BLK WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Headlights circuit (2 of 2) -> HIGH VARIANT ROOF FUNCTION
