BMW 7 series F01/F02 (2008-2012) capacitor suppression interference ignition coils Wiring diagram
This page shows the only wiring diagram for the component.capacitor suppression interference ignition coils, which is found in the car BMW 7 series F01/F02 (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram capacitor suppression interference ignition coils (1 of 1)
ACTIVATION
BLU/GRY WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CAPACITOR SUPPRESSION INTERFERENCE IGNITION COILS
CAS BUS SIG
COMPUTER DATA LINES SYSTEM
COOLING FANS SYSTEM
CYLINDER 10
CYLINDER 11
CYLINDER 12
CYLINDER 7
CYLINDER 8
CYLINDER 9
DIGITAL MOTOR ELECTRONICS 2 (LEFT SIDE OF
ENGINE COMPT)
FLEXRAY BUS SIG
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/YEL WIRE
IGNITION COILS CYLINDER
NCA WIRE
PNK/BLU WIRE
PT-CAN BUS SIG
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
SPARK PLUG
START SIG
SUPPLY, TERMINAL 15
VIO WIRE
WAKE UP SIG
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 6.0l turbo (8 of 9) -> CAPACITOR SUPPRESSION INTERFERENCE IGNITION COILS
