BMW 7 series E65/E66 facelift (2005-2008) Semi electric power steering column circuit

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 GND BLK/RED WIRE BLK/WHT WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE CAR ACCESS CONTROL MODULE CHASSIS INTEGRATION MODULE (CIM) (2007: UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DME CONTROL MODULE (2007: RIGHT REAR OF ENGINE COMPT) DYNAMIC DRIVE CONTROL MODULE (2007: RIGHT SIDE OF RIGHT FOOTWELL) DYNAMIC STABILITY CONTROL MODULE (DSC) (RIGHT SIDE OF ENGINE COMPT) FRONT FUSE HOLDER (RIGHT SIDE OF DASH) FUSE GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES PARTLY ELECTRIC STEERING COLUMN MOTOR RED/BLK WIRE SERVOTRONIC SOLENOID VALVE (UNDER LEFT FRONT OF VEHICLE) WHT WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
