BMW 7 series E65/E66 facelift (2005-2008) rear left receive antenna Wiring diagram
This page shows the only wiring diagram for the component.rear left receive antenna, which is found in the car BMW 7 series E65/E66 facelift (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear left receive antenna (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
FRONT LEFT RECEIVE ANTENNA
FRONT RIGHT RECEIVE ANTENNA
FUSE
FUSE HOLDER
GRN WIRE
GRN/ORG WIRE
HOT AT ALL TIMES
NCA WIRE
REAR LEFT RECEIVE ANTENNA
REAR RIGHT RECEIVE ANTENNA
RED WIRE
RED/BLU WIRE
TIRE PRESSURE SYSTEM CONTROL UNIT
WHT WIRE
Go to component -> Tire pressure monitoring circuit -> REAR LEFT RECEIVE ANTENNA
