BMW 7 series E65/E66 facelift (2005-2008) passenger's side rear seat module Wiring diagrams
This page contains all the electrical diagrams for the component. passenger's side rear seat module, in which he is found in the car BMW 7 series E65/E66 facelift (2005-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passenger's side rear seat module (1 of 2)
12 11 48 50 14 13 49 15 K-CAN PH K-CAN PL WUP WUP K-CAN SH K-CAN SL WUP PA-BUS
15 6 12 K-CAN PL K-CAN PH PA-BUS
30 16 32 WUP K-CAN PL K-CAN PH
5 6 K-CAN PL K-CAN PH
6 15 12 K-CAN PH K-CAN PL PA-BUS
6 5 K-CAN PH K-CAN PL
9 12 15 6 PA-BUS PA-BUS K-CAN PL K-CAN PH
BLU WIRE
BLU/VIO WIRE
CAR ACCESS CONTROL MODULE
COMFORT ACCESS CONTROL MODULE
DRIVER'S DOOR MODULE (DRIVER'S DOOR)
DRIVER'S SEAT MODULE
DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
DRIVER'S SIDE REAR DOOR MODULE
DRIVER'S SIDE REAR OUTER DOOR HANDLE ELECTRONIC MODULE
DRIVER'S SIDE REAR SEAT MODULE
GRN WIRE
GRN/ORG WIRE
GRY/BLK WIRE
GRY/BRN WIRE
K-CAN PH
K-CAN PL
PA-BUS
PASSENGER'S DOOR MODULE (RIGHT FRONT DOOR)
PASSENGER'S SEAT MODULE
PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
PASSENGER'S SIDE REAR DOOR MODULE
PASSENGER'S SIDE REAR OUTER DOOR HANDLE ELECTRONIC MODULE
PASSENGER'S SIDE REAR SEAT MODULE
POWER MODULE (RIGHT REAR LUGGAGE COMPT)
RED/GRN WIRE
TRUNK LID/TAILGATE MODULE
WHT WIRE
WHT/RED WIRE
Go to component -> High/low bus circuit, early production (2 of 3) -> PASSENGER'S SIDE REAR SEAT MODULE
Wiring diagram passenger's side rear seat module (2 of 2)
12 11 50 14 13 49 15 K-CAN PH K-CAN PL WUP K-CAN SH K-CAN SL WUP PA-BUS
15 6 12 K-CAN PL K-CAN PH PA-BUS
30 16 32 WUP K-CAN PL K-CAN PH
5 6 K-CAN PL K-CAN PH
6 15 12 K-CAN PH K-CAN PL PA-BUS
6 5 K-CAN PH K-CAN PL
9 12 15 6 PA-BUS PA-BUS K-CAN PL K-CAN PH
BLU WIRE
BLU/VIO (OR VIO) WIRE
BLU/VIO WIRE
CAR ACCESS CONTROL MODULE
COMFORT ACCESS CONTROL MODULE (2007: RIGHT SIDE OF REAR COMPT)
DRIVER'S DOOR MODULE (DRIVER'S DOOR)
DRIVER'S SEAT MODULE
DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
DRIVER'S SIDE REAR OUTER DOOR HANDLE ELECTRONIC MODULE
DRIVER'S SIDE REAR SEAT MODULE
GRN WIRE
GRN/ORG WIRE
GRY/BLK WIRE
GRY/BRN WIRE
K-CAN PH
K-CAN PL
PA-BUS
PASSENGER'S DOOR MODULE (RIGHT FRONT DOOR)
PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE
PASSENGER'S SIDE REAR OUTER DOOR HANDLE ELECTRONIC MODULE
PASSENGER'S SIDE REAR SEAT MODULE
POWER MODULE (RIGHT REAR LUGGAGE COMPT)
RED/BLU/YEL WIRE
TRUNK LID/TAILGATE MODULE (2007: RIGHT REAR OF REAR COMPT)
WHT WIRE
WHT/RED WIRE
Go to component -> High/low bus circuit, late production (2 of 3) -> PASSENGER'S SIDE REAR SEAT MODULE
