BMW 7 series E65/E66 facelift (2005-2008) left front mid-range speaker Wiring diagram
This page shows the only wiring diagram for the component.left front mid-range speaker, which is found in the car BMW 7 series E65/E66 facelift (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front mid-range speaker (1 of 1)
AUDIO SYSTEM CONTROLLER
BLK WIRE
BLK/BRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/RED WIRE
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/ORG WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CD CHANGER
COMPUTER DATA LINES SYSTEM
ELECTRONIC STEERING WHEEL MODULE (2007: PART OF STEERING WHEEL)
FRONT FUSE HOLDER (RIGHT SIDE OF DASH)
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES FUSE
LEFT FRONT MID-RANGE SPEAKER
LEFT FRONT SUBWOOFER
LEFT FRONT TWEETER
LEFT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK
LEFT REAR MID-RANGE SPEAKER
MICROPHONE (2007: LEFT FRONT CORNER OF ROOF)
NCA WIRE
REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FRONT MID-RANGE SPEAKER
RIGHT FRONT SUBWOOFER
RIGHT FRONT TWEETER
RIGHT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK
RIGHT REAR MID-RANGE SPEAKER
STEERING COLUMN SWITCH CLUSTER
TELEPHONE TRANSCEIVER (2007: LEFT REAR OF REAR COMPT)
VOICE INPUT CONTROL MODULE
WHT WIRE
YEL/BRN WIRE
YEL/GRN WIRE
Go to component -> Premium radio circuit, hifi, without amp amplifier -> LEFT FRONT MID-RANGE SPEAKER
