BMW 7 series E65/E66 facelift (2005-2008) left front makeup mirror switch Wiring diagram
This page shows the only wiring diagram for the component.left front makeup mirror switch, which is found in the car BMW 7 series E65/E66 facelift (2005-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front makeup mirror switch (1 of 1)
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
COOLER BOX (W/ REAR COMPARTMENT AIR CONDITIONING)
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR ENTRANCE LIGHT
DRIVER'S DOOR EXIT LIGHT
DRIVER'S DOOR MODULE (DRIVER'S DOOR)
DRIVER'S DOOR SWITCH BLOCK
FRONT
FRONT INTERIOR LIGHT
FUSE FUSE HOLDER (RIGHT SIDE OF DASH)
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR
LEFT FRONT ENTRANCE LIGHT
LEFT FRONT MAKEUP MIRROR LIGHT
LEFT FRONT MAKEUP MIRROR SWITCH
LIGHT
MAP READING
MAP READING LIGHT
OFF
OFF OFF ON ON
OFF ON
OFF ON ON
REAR CENTER MAKEUP MIRROR LIGHT
REAR INTERIOR LIGHT
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/WHT/YEL WIRE
RED/YEL WIRE
RIGHT FRONT MAKEUP MIRROR LIGHT
RIGHT FRONT MAKEUP MIRROR SWITCH
TOP
WHT/BRN WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> LEFT FRONT MAKEUP MIRROR SWITCH
