BMW 7 series E65/E66 (2001-2005) rear passenger's power window motor Wiring diagram
This page shows the only wiring diagram for the component.rear passenger's power window motor, which is found in the car BMW 7 series E65/E66 (2001-2005). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear passenger's power window motor (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE REAR DOOR MODULE
FRONT FUSE HOLDER (RIGHT SIDE OF DASH)
FUSE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) FUSE
PASSENGER'S SIDE REAR DOOR MODULE
REAR DRIVER'S POWER WINDOW MOTOR
REAR PASSENGER'S POWER WINDOW MOTOR
RED/BRN WIRE
RED/YEL WIRE
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Rear windows circuit -> REAR PASSENGER'S POWER WINDOW MOTOR
