BMW 7 series E65/E66 (2001-2005) mechatronics oxygen sensor 2 behind catalytic converter Wiring diagram

BLK WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BRN WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE DME RELAY 3 ENGINE CONTROL MODULE I (DME) (2007: RIGHT REAR OF ENGINE COMPT) FROM INTEGRATED SUPPLY MODULE OF DME RELAY 2 (DIAGRAM 1 OF 10) FUSE FUSE TERMINAL POINT GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES INTEGRATED SUPPLY MODULE (IVM) (2007: RIGHT REAR OF ENGINE COMPT) JUMP START MECHATRONICS OXYGEN SENSOR 2 BEHIND CATALYTIC CONVERTER NCA WIRE OXY SENS HEAT SIG OXY SENS SIG OXYGEN SENSOR 2 BEFORE CATALYTIC CONVERTER (2007: REAR OF ENGINE) OXYGEN SENSOR BEFORE CATALYTIC CONVERTER (2007: REAR OF ENGINE) OXYGEN SENSOR BEHIND CATALYTIC CONVERTER RED WIRE RED/WHT WIRE RED/WHT/YEL WIRE TERM 85 SPLY WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE
