BMW 7 series E65/E66 (2001-2005) grn Wiring diagrams

This page contains all the electrical diagrams for the component. grn, in which he is found in the car BMW 7 series E65/E66 (2001-2005). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

grn wiring diagram (61 of 104)

2004 EARLY PRODUCTION ANTENNA AMPLIFIER (W/ REMOTE CONTROL RECEIVER) ANTENNA DIVERSITY (2007: BOTTOM OF LEFT "C" PILLAR) BRN/BLK WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DIGITAL TUNER US FRONT FUSE HOLDER GRN WIRE HOT AT ALL TIMES FUSE HOT AT ALL TIMES FUSE (RIGHT SIDE OF DASH) NCA WIRE REAR-WINDOW AERIAL RED/GRN WIRE RED/GRY WIRE WHT/VIO WIRE

Go to component -> Antenna diversity circuit -> GRN WIRE

grn wiring diagram (62 of 104)

2004 TO 2005 EARLY PRODUCTION 2005 MID YEAR PRODUCTION ANTENNA TUNER AUDIO SYSTEM CONTROL CD CHANGER DATA BUS CIRCUIT DISPLAY MODULE GRN WIRE INSTRUMENT CLUSTER MULTIMEDIA CHANGER NAVIGATION CONTROL MODULE REAR COMPARTMENT DISPLAY CONTROL MODULE SATELLITE RECEIVER TRANSCEIVER TELEPHONE VIDEO MODULE VOICE INPUT CONTROL MODULE

Go to component -> Most data bus circuit -> GRN WIRE

grn wiring diagram (63 of 104)

1 2 3 4 5 6 7 8 9 10 11 12 13 SUPPLY GND BRN WIRE BRN/BLU WIRE BRN/YEL WIRE CAN BUS SIG CAN BUS SIG COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/ORG WIRE GRY/BLK WIRE HOT AT ALL TIMES REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) RED/GRY WIRE SNRF SW GND SNRF SW SIG SNRF SW SIG SNRF SW SIG LIGHTING SIG SUNROOF MODULE (FRONT OF ROOF) SUNROOF SWITCH YEL/GRN WIRE YEL/WHT WIRE

Go to component -> Power top/sunroof circuit -> GRN WIRE

grn wiring diagram (64 of 104)

AUDIO SYSTEM CONTROLLER BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE BRN/YEL WIRE CD CHANGER COMPUTER DATA LINES SYSTEM ELECTRONIC STEERING WHEEL MODULE FRONT FUSE HOLDER (RIGHT SIDE OF DASH) GRN WIRE GRN/RED WIRE HIFI AMPLIFIER HOT AT ALL TIMES FUSE LEFT FRONT MID-RANGE SPEAKER LEFT FRONT SUBWOOFER LEFT FRONT TWEETER LEFT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK LEFT REAR MID-RANGE SPEAKER MICROPHONE NCA WIRE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT SUBWOOFER RIGHT FRONT TWEETER RIGHT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK RIGHT REAR MID-RANGE SPEAKER STEERING COLUMN SWITCH CLUSTER TELEPHONE TRANSCEIVER VOICE INPUT CONTROL MODULE WHT WIRE YEL/BRN WIRE YEL/GRN WIRE

Go to component -> Premium radio circuit, hifi without amp amplifier -> GRN WIRE

grn wiring diagram (65 of 104)

AUDIO SYSTEM CONTROLLER BLK WIRE BLK/BRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE CD CHANGER CENTER SPEAKER COMPUTER DATA LINES SYSTEM ELECTRONIC FRONT FUSE HOLDER (RIGHT SIDE OF DASH) GRN WIRE GRN/RED WIRE GRY/YEL WIRE HIFI AMPLIFIER HOT AT ALL TIMES FUSE LEFT FRONT SUBWOOFER LEFT FRONT TWEETER LEFT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK LEFT REAR DOOR MIDRANGE SPEAKER LEFT REAR MID RANGE LEFT FRONT SPEAKER MID RANGE SPEAKER MICROPHONE MODULE NCA WIRE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT MID-RANGE SPEAKER RIGHT FRONT SUBWOOFER RIGHT FRONT TWEETER RIGHT MULTIFUNCTION STEERING WHEEL SWITCH BLOCK RIGHT REAR DOOR MIDRANGE SPEAKER RIGHT REAR MID-RANGE SPEAKER STEERING COLUMN SWITCH CLUSTER STEERING WHEEL) TELEPHONE TRANSCEIVER VOICE INPUT CONTROL MODULE WHT WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE

Go to component -> Premium radio circuit, top hifi, hifi with amp amplifier -> GRN WIRE

grn wiring diagram (66 of 104)

1 2 3 4 5 6 7 8 GND 1 2 3 4 5 6 7 8 GND GND BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BRN WIRE BRN/GRN WIRE BRN/YEL WIRE BUS SIG BUS SIG SPLY GND COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES LEFT REAR SEAT CONTROL SWITCH NCA WIRE REAR COMPARTMENT CENTER CONSOLE CONTROL CENTER REAR DRIVER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR DRIVER'S SIDE SEAT LUMBAR SUPPORT MOTOR REAR DRIVER'S SIDE SEAT MODULE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) REAR PASSENGER'S SIDE LUMBAR SUPPORT VALVE BLOCK REAR PASSENGER'S SIDE SEAT LUMBAR SUPPORT MOTOR REAR PASSENGER'S SIDE SEAT MODULE RED/BRN WIRE RED/YEL WIRE RIGHT REAR SEAT CONTROL SWITCH VALVE VALVE 2 VALVE 1 VALVE 3 VALVE 4 WHT/BLU WIRE WHT/YEL WIRE

Go to component -> Rear lumbar circuit -> GRN WIRE

grn wiring diagram (67 of 104)

2004 TO 2006 EARLY PRODUCTION BLK WIRE BLU WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FRONT FUSE HOLDER (RIGHT SIDE OF DASH) FUSE GRN WIRE GRN/ORG WIRE HEADSET INTERFACE (2007: LEFT SIDE OF REAR COMPT) HOT AT ALL TIMES NCA WIRE REAR COMPARTMENT AUDIO OPERATING UNIT REAR COMPARTMENT CENTER CONSOLE CONTROL CENTER REAR COMPARTMENT DISPLAY CONTROL MODULE (2007: REAR OF CENTER CONSOLE) REAR COMPARTMENT MONITOR REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) RED WIRE RED/BLK/YEL WIRE RED/YEL WIRE VIDEO MODULE ((2007: LEFT SIDE OF REAR COMPT) YEL WIRE

Go to component -> Rear seat entertainment circuit -> GRN WIRE

grn wiring diagram (68 of 104)

1 2 3 4 5 6 7 8 GND 1 2 3 4 5 6 7 8 GND GND BLK WIRE BLU WIRE BLU/VIO WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE BUS SIG BUS SIG SPLY GND COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES LEFT REAR SEAT CONTROL SWITCH NCA WIRE REAR COMPARTMENT CENTER CONSOLE CONTROL CENTER REAR DRIVER'S SIDE SEAT BACKREST FAN 1 REAR DRIVER'S SIDE SEAT BACKREST FAN 2 REAR DRIVER'S SIDE SEAT BACKREST FAN 3 REAR DRIVER'S SIDE SEAT BACKREST FAN 4 REAR DRIVER'S SIDE SEAT CUSHION FAN 1 REAR DRIVER'S SIDE SEAT CUSHION FAN 2 REAR DRIVER'S SIDE SEAT CUSHION FAN 3 REAR DRIVER'S SIDE SEAT CUSHION FAN 4 REAR DRIVER'S SIDE SEAT CUSHION FAN 5 REAR DRIVER'S SIDE SEAT MODULE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) REAR PASSENGER'S SIDE SEAT BACKREST FAN 1 REAR PASSENGER'S SIDE SEAT BACKREST FAN 2 REAR PASSENGER'S SIDE SEAT BACKREST FAN 3 REAR PASSENGER'S SIDE SEAT BACKREST FAN 4 REAR PASSENGER'S SIDE SEAT CUSHION FAN 1 REAR PASSENGER'S SIDE SEAT CUSHION FAN 2 REAR PASSENGER'S SIDE SEAT CUSHION FAN 3 REAR PASSENGER'S SIDE SEAT CUSHION FAN 4 REAR PASSENGER'S SIDE SEAT CUSHION FAN 5 REAR PASSENGER'S SIDE SEAT MODULE RED WIRE RED/BRN WIRE RED/YEL WIRE RIGHT REAR SEAT CONTROL SWITCH WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE

Go to component -> Rear seat ventilation circuit -> GRN WIRE

grn wiring diagram (69 of 104)

2004 EARLY PRODUCTION 2004 LATE PRODUCTION TO 2007 BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE HOT AT ALL TIMES FUSE NCA WIRE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) RED/WHT WIRE SATELLITE ANTENNA SATELLITE RECEIVER (2007: TOP LEFT REAR SIDE OF REAR COMPT)

Go to component -> Satellite radio circuit -> GRN WIRE

grn wiring diagram (70 of 104)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 GND 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 VIDEO SIG BLK WIRE BLU WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM CONTROL DISPLAY ELECTRONIC NIGHT VISION MODULE GRN WIRE HOT AT ALL TIMES REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) FUSE MULTIMEDIA CHANGER (2007: LEFT SIDE OF REAR COMPT) NAVIGATION SYSTEM NCA WIRE REAR COMPARTMENT DISPLAY CONTROL MODULE (2007: REAR OF CENTER CONSOLE) REAR WINDOW SERIAL RED WIRE RED/WHT WIRE SHLD SHLD SHLD SPLY TERMINAL 30 VIDEO MODULE ((2007: LEFT SIDE OF REAR COMPT) VIDEO SIG VIDEO SIG GREEN VIDEO SIG BLUE VIDEO SIG GREEN VIDEO SIG BLUE SHLD VIDEO SIG RED WIRE W/ DIGITAL TELEVISION WHT WIRE

Go to component -> Video system circuit, with navigation & with rear compt display -> GRN WIRE
