BMW 7 series E65/E66 (2001-2005) elec throttle vlv can-bus sig elec throttle vlv gnd Wiring diagram

2004 TO 2006 EARLY PRODUCTION 2006 LATE PRODUCTION TO 2007 BLK WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE CHARCOAL FILTER VALVE CRANKSHAFT POSITION SENSOR (2007: UNDER FRONT CENTER OF VEHICLE) DIGITAL GROUND CAN-BUS SIG DME RELAY 1 DME RELAY 2 ELEC THROTTLE VLV CAN-BUS SIG ELEC THROTTLE VLV GND ELEC THROTTLE VLV ELEC THROTTLE VLV SIG FUEL INJECTOR GND ELECTRIC THROTTLE VALVE ACTUATOR ENGINE CONTROL MODULE I (DME) (2007: RIGHT REAR OF ENGINE COMPT) ENGINE COOLANT TEMPERATURE SENSOR (2007: LEFT FRONT OF ENGINE COMPT) EXHAUST CAMSHAFT SENSOR FUEL PRESSURE SENSOR (2007: FRONT OF ENGINE COMPT) FUSE GRN/VIO WIRE GRN/WHT WIRE GRY BRN/ WIRE GRY WIRE GRY/BRN WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT AT ALL TIMES FRONT FUSE HOLDER (RIGHT SIDE OF DASH) FUSE INTAKE CAMSHAFT SENSOR INTEGRATED SUPPLY MODULE (IVM) KNOCK SENS SIG KNOCK SENS SIG KNOCK SENS SIG KNOCK SENSOR NCA WIRE RED WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/WHT/YEL WIRE TANK VENT VLV SIG SOLENOID VLV SIG TO INTEGRATED SUPPLY MODULE OF DME RELAY 3 (DIAGRAM 5 OF 10) VVT CTRL MODULE SIG ALTERNATOR SIG WHT/BLK WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
