BMW 7 series E65/E66 (2001-2005) 9 12 15 6 pa-bus pa-bus k-can pl k-can ph Wiring diagram

12 11 48 50 14 13 49 15 K-CAN PH K-CAN PL WUP WUP K-CAN SH K-CAN SL WUP PA-BUS 15 6 12 K-CAN PL K-CAN PH PA-BUS 30 16 32 WUP K-CAN PL K-CAN PH 5 6 K-CAN PL K-CAN PH 6 15 12 K-CAN PH K-CAN PL PA-BUS 6 5 K-CAN PH K-CAN PL 9 12 15 6 PA-BUS PA-BUS K-CAN PL K-CAN PH BLU WIRE BLU/VIO WIRE CAR ACCESS CONTROL MODULE COMFORT ACCESS CONTROL MODULE DRIVER'S DOOR MODULE (DRIVER'S DOOR) DRIVER'S SEAT MODULE DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE DRIVER'S SIDE REAR DOOR MODULE DRIVER'S SIDE REAR OUTER DOOR HANDLE ELECTRONIC MODULE DRIVER'S SIDE REAR SEAT MODULE GRN WIRE GRN/ORG WIRE GRY/BLK WIRE GRY/BRN WIRE K-CAN PH K-CAN PL PA-BUS PASSENGER'S DOOR MODULE (RIGHT FRONT DOOR) PASSENGER'S SEAT MODULE PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE PASSENGER'S SIDE REAR DOOR MODULE PASSENGER'S SIDE REAR OUTER DOOR HANDLE ELECTRONIC MODULE PASSENGER'S SIDE REAR SEAT MODULE POWER MODULE (RIGHT REAR LUGGAGE COMPT) RED/GRN WIRE TRUNK LID/TAILGATE MODULE WHT WIRE WHT/RED WIRE
