BMW 7 series E65/E66 (2001-2005) 2004 late production to 2007 Wiring diagrams

2004 EARLY PRODUCTION 2004 LATE PRODUCTION TO 2007 BLK WIRE BLU/RED WIRE BRN WIRE ELECTRONIC STEERING WHEEL MODULE (2007: PART OF STEERING WHEEL) FRONT FUSE HOLDER (RIGHT SIDE OF DASH) FUSE GRN WIRE HORN SWITCH HOT AT ALL TIMES LEFT FANFARE HORN (LOW- PITCHED) (2007: UNDER LEFT SIDE OF FRONT BUMPER) RED WIRE RED/WHT WIRE RIGHT FANFARE HORN (HIGH- PITCHED) (2007: UNDER RIGHT SIDE OF FRONT BUMPER) SAFETY INFORMATION MODULE (SIM) SAFETY, GATEWAY MODULE (2007: UNDER RIGHT SIDE OF DASH) STEERING COLUMN SWITCH CLUSTER VIO WIRE VIO/BLU WIRE WHT WIRE

2004 LATE PRODUCTION TO 2007 BLK WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE EARLY PRODUCTION FUSE GRY/RED WIRE HOT AT ALL TIMES LEFT REAR HEAD RESTRAINT ADJUSTMENT MOTOR LEFT REAR SEAT HEATING, HEAD RESTRAINT ADJUSTMENT SWITCH UNIT NCA WIRE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) REAR SEAT SATELLITE (2007: UNDER REAR CENTER CONSOLE) RED/WHT WIRE SAFETY INFORMATION MODULE (SIM) SAFETY, GATEWAY MODULE WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

2004 LATE PRODUCTION TO 2007 BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE EARLY PRODUCTION FUSE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES NCA WIRE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) REAR SEAT SATELLITE RED/WHT WIRE RIGHT REAR HEAD RESTRAINT ADJUSTMENT MOTOR RIGHT REAR SEAT HEATING, HEAD RESTRAINT ADJUSTMENT SWITCH UNIT SAFETY INFORMATION MODULE (SIM) SAFETY, GATEWAY MODULE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

2004 EARLY PRODUCTION 2004 LATE PRODUCTION TO 2007 BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE HOT AT ALL TIMES FUSE NCA WIRE REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) RED/WHT WIRE SATELLITE ANTENNA SATELLITE RECEIVER (2007: TOP LEFT REAR SIDE OF REAR COMPT)

2004 EARLY PRODUCTION 2004 LATE PRODUCTION TO 2007 AIR PUMP SIG ANTI-LOCK BRAKES SYSTEM APP SENS GND APP SENS SPLY APPSENS SIG BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRN/YEL WIRE BLK/GRY WIRE BLK/RED WIRE BLK/RED/WHT WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/WHT/GRN WIRE BLK/YEL WIRE BLK/YEL/RED WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BRK LT SIG BRN WIRE BRN/BLK WIRE BRN/BLK/WHT WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/YEL WIRE CAN BUS SIG CENTRAL GATEWAY MODULE (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DIAG VLV SIG E-BOX SIG ELECTRIC FUEL PUMP (BELOW RIGHT REAR SEAT) ENGINE CONTROL MODULE I (DME) EXH FLAP SIG FAN SIG FUEL INJECTOR 1, CYLINDER (2007: TOP LEFT OF ENGINE) FUEL INJECTORS, CYLINDERS (2007: TOP OF ENGINE) GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY BRN/ WIRE GRY WIRE HEATING SIG HOT AT ALL TIMES REAR FUSE HOLDER (RIGHT REAR LUGGAGE COMPT) FUSE IMMOB SIG INSTRUMENT CLUSTER SYSTEM LT TEST SIG OIL SW SIG PUMP SIG RED WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/WHT/YEL WIRE RIGHT B-PILLAR SATELLITE (2007: BOTTOM OF RIGHT "B" PILLAR) RR SPD SIG SAFETY INFORMATION MODULE SAFETY, GATEWAY MODULE (2007: UNDER RIGHT SIDE OF DASH) SPD SIG ST RLY SIG STARTING/ CHARGING SYSTEM TEMP SIG TERM 15 SIG TERM 50 SIG UNDER RIGHT FRONT SEAT) (2005 LATE PRODUCTION TO 2007) VENTI VLV SIG WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE
