BMW 7 series E65/E66 (2001-2005) 12 11 10 9 8 7 6 5 4 3 2 1 pwr Wiring diagram

12 11 10 9 8 7 6 5 4 3 2 1 PWR 2004 EARLY PRODUCTION 2004 LATE PRODUCTION TO 2005 EARLY PRODUCTION 26 36 37 WAKE-UP SIG CAN-BUS SIG CAN-BUS SIG 8 5 PWR GND ACCELERATOR PEDAL MODULE ACTIVE CRUISE CONTROL (ACC) MODULE (IF EQUIPPED) BLU WIRE BLU/RED WIRE BRAKE LIGHT SWITCH (LEFT SIDE OF DASH) BRAKE LT SIG BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BUS SIGNAL GROUND CENTRAL GATEWAY MODULE (ZGM) (RIGHT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CRUISE CONTROL STEERING COLUMN SWITCH ELECTRIC THROTTLE VALVE ACTUATOR ELECTRIC THROTTLE VALVE ACTUATOR 2 ENGINE CONTROL MODULE I (DME) ENGINE CONTROL MODULE II (DME) FRONT FUSE HOLDER (RIGHT SIDE OF DASH) FUSE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ DME RELAY 1 ENERGIZED HOT W/ DME RELAY 2 ENERGIZED INTEGRATED SUPPLY MODULE (IVM) FUSE PWR RED WIRE RED/BLU/YEL WIRE RED/GRN WIRE RED/WHT WIRE RED/WHT/YEL WIRE SAFETY INFORMATION MODULE (SIM) SAFETY, GATEWAY MODULE STEERING COLUMN SWITCH CLUSTER VIO WIRE WAKE-UP SIG BUS SIGNAL WHT WIRE WHT/BLU WIRE WHT/GRN WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE
