Rear heated seats circuit for BMW 7 series E38 facelift (1998-2001)
Rear heated seats circuit
BLK/YEL WIRE
BRN WIRE
FUSE
FUSE BOX (RIGHT SIDE OF LUGGAGE COMPT)
GRN/WHT WIRE
GRY/RED WIRE
HOT IN RUN OR START
LEFT REAR SEAT HEATER
LEFT REAR SEAT HEATER SWITCH
LEFT REAR SEATBACK HEATER
RIGHT REAR SEAT HEATER
RIGHT REAR SEAT HEATER SWITCH
RIGHT REAR SEATBACK HEATER
WHT/BRN WIRE
WHT/YEL WIRE
YEL/BRN WIRE
