Ground distribution circuit for BMW 7 series E38 facelift (1998-2001)

ABS/ASC OR ABS/DSC CONTROL MODULE BATTERY BRN WIRE BRN/BLK WIRE ELECTRONIC SHOCK ABSORBER CONTROL MODULE (EDC) HEADLIGHT WASHER PUMP LEFT "B" PILLAR LIGHT LEFT FOG LIGHT LEFT HORN LEFT FRONT AUXILIARY TURN LIGHT LEFT FRONT SENSOR (AIRBAG) LEFT HEADLIGHT LEFT REAR ACCESS LIGHT LEFT REAR ASHTRAY LIGHT LEFT REAR DOOR HANDLE LIGHT LEFT REAR DOOR JAMB SWITCH LEFT REAR DOOR OPENER LIGHTING LEFT REAR FOOTWELL LIGHT LEFT REAR INTERIOR LIGHT LEFT REAR POWER WINDOW SWITCH LEFT REAR WINDOW PRESSURE SENSITIVE FINGER GUARD LEFT WASHER JET HEATER DRIVER'S SIDE FOOTWELL LIGHT MAYDAY SWITCH NCA WIRE PARK DISTANCE CONTROL MODULE RAIN SENSOR REAR LID TILT SWITCH RIGHT FOG LIGHT RIGHT HEADLIGHT RIGHT FRONT AUXILIARY TURN LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT FRONT SENSOR (AIRBAG) RIGHT HORN RIGHT WASHER JET HEATER SUPPLEMENTAL RESTRAINT SYSTEM CONTROL MODULE W/ 2000 LATE PROD, 2001 ASC DSC 2 3 WIPER MOTOR

BLOWER RELAY BRN WIRE COIL SPRING DRIVER'S ACTIVE SEAT CONTROL UNIT DRIVER'S DOOR ACCESS LIGHT DRIVER'S DOOR MODULE DRIVER'S HEADREST MOTOR DRIVER'S SEAT CUSHION TILT MOTOR DRIVER'S SEAT MOVEMENT MOTOR DRIVER'S SEAT HEATER DRIVER'S SEAT HEIGHT MOTOR DRIVER'S SEAT LUMBAR SUPPORT SWITCH DRIVER'S SEAT LUMBAR SUPPORT VALVE BLOCK DRIVER'S SEATBACK HEAD RECLINER MOTOR DRIVER'S SEATBACK HEATER DRIVER'S SEATBACK RECLINER MOTOR DRIVER'S SIDE PRESSURE, SENSITIVE FINGER GUARD DRIVER'S THIGH SUPPORT MOTOR DRIVERS DOOR JAMB SWITCH FINAL STAGE UNIT FRONT CIGAR LIGHTER GENERAL MODULE HEADLIGHT WASHER MODULE LEFT ACCESSORY TABLE LIGHT LEFT FRONT DOOR OPENER LIGHTING LEFT FRONT DOOR HANDLE LIGHT MEMORY SWITCH NCA WIRE PASSENGER'S SEAT HEATER PASSENGER'S SEATBACK HEATER PASSENGER'S SIDE FOOTWELL LIGHT REAR AREA FUSE ADJUSTER LIGHTS MIXING ACTUATOR LIGHTS REAR CIGAR LIGHTER FRONT DEFOGGER RIGHT ACCESSORY TABLE LIGHT SEAT/ STEERING COLUMN MEMORY CONTROL MODULE SECONDARY AIR INJECTION PUMP RELAY SOFT CLOSE TRUNK LID MOTOR ASSEMBLY STEERING COLUMN LENGTH ADJUST MOTOR STEERING COLUMN ANGLE ADJUST MOTOR W/O MEMORY WIPER RELAY

BRN WIRE HEATING AND A/C CONTROL MODULE LIGHT MODULE OBDII PLUG PASSENGER'S ACTIVE SEAT CONTROL UNIT PASSENGER'S DOOR ACCESS LIGHT PASSENGER'S DOOR JAMB SWITCH PASSENGER'S DOOR MODULE PASSENGER'S MEMORY SWITCH PASSENGER'S POWER WINDOW SWITCH PASSENGER'S SEAT ADJUSTMENT SWITCH PASSENGER'S SEAT CUSHION TILT MOTOR PASSENGER'S SEAT HEATER PASSENGER'S SEAT HEIGHT MOTOR PASSENGER'S SEAT LUMBAR SUPPORT SWITCH PASSENGER'S SEAT LUMBAR SUPPORT VALVE BLOCK PASSENGER'S SEAT MEMORY CONTROL MODULE PASSENGER'S SEAT MOVEMENT MOTOR PASSENGER'S SEATBACK HEAD ADJUSTMENT SWITCH PASSENGER'S SEATBACK HEAD RECLINER MOTOR PASSENGER'S SEAT HEADREST MOTOR PASSENGER'S SEATBACK HEATER PASSENGER'S SEATBACK RECLINER MOTOR PASSENGER'S THIGH SUPPORT MOTOR PASSENGER'S SIDE PRESSURE- SENSITIVE FINGER GUARD PASSENGER'S THIGH SUPPORT SWITCH REAR COMPT AIR CONDITIONING OUTPUT STAGE REAR COMPT BLOWER MOTOR REAR COMPT BLOWER CONTROL MODULE REAR LID MOTOR RELAY RIGHT "B" PILLAR LIGHT RIGHT ACCESSORY TABLE LIGHT RIGHT FRONT DOOR HANDLE LIGHT RIGHT FRONT DOOR OPENER LIGHTING RIGHT REAR ASHTRAY LIGHT RIGHT REAR DOOR HANDLE LIGHT REAR RIGHT DOOR JAMB SWITCH RIGHT REAR DOOR OPENER LIGHTING RIGHT REAR POWER WINDOW SWITCH RIGHT REAR ACCESS LIGHT RIGHT REAR WINDOW PRESSURE- SENSITIVE FINGER GUARD W/ MEMORY WITHOUT MEMORY

BRN WIRE DRIVER'S MAKEUP MIRROR SWITCH FRONT INTERIOR/ READING LIGHT ELECTRIC FAN ELECTROCHROMIC REAR VIEW MIRROR FUEL PUMP GARAGE DOOR OPENER HEADLIGHT WASHER PUMP HIGH LEVEL STOP LIGHT HYDRAULIC UNIT SUNROOF MODULE INTENSIVE WASHER PUMP LEFT REAR SEAT BELT SWITCH LEFT REAR SEAT CONTROL HEAD- REST SWITCH LEFT REAR SEAT HEATER LEFT REAR SEAT HEATER RIGHT REAR SEAT HEATER LEFT REAR SEAT HEATER SWITCH LEFT REAR SEAT LUMBAR SUPPORT SWITCH LEFT REAR SEAT LUMBAR SUPPORT VALVE BLOCK LEFT REAR SEATBACK HEATER PASSENGER'S MAKEUP MIRROR SWITCH PASSENGER'S SEAT HEATER REAR HEADREST CONTROL MODULE RIGHT REAR FOOTWELL LIGHT RIGHT REAR INTERIOR LIGHT RIGHT REAR SEAT BELT SWITCH RIGHT REAR SEAT CONTROL HEAD- REST SWITCH RIGHT REAR SEAT CONTROL HEAD- REST SWITCH LEFT REAR SEAT LUMBAR SUPPORT SWITCH RIGHT REAR SEAT HEATER RIGHT REAR SEAT HEATER SWITCH RIGHT REAR SEAT LUMBAR SUPPORT SWITCH RIGHT REAR SEAT LUMBAR SUPPORT VALVE BLOCK SECONDARY AIR INJECTION PUMP TRAILER CONNECTOR TRAILER MODULE (AHM) WASHER PUMP

"B" PILLAR LIGHTS RELAY COIL SPRING ACTIVE CRUISE CONTROL UNIT ANTI- THEFT HORN BRAKE FLUID LEVEL SWITCH BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE CENTRAL LOCKING FUEL TANK ACCESS FLAP RELAY CHIME MODULE COMBINATION SWITCH DIMMER COOLER BOX DRIVER'S SEAT BELT SWITCH ENGINE COOLANT LEVEL SWITCH FOG LIGHT SWITCH HEADLIGHT WIDENING CONTROL MODULE CLUTCH PEDAL POSITION SWITCH INSTRUMENT CLUSTER INTEGRATED INSTRUMENT CLUSTER CONTROL MODULE LEFT LICENSE PLATE LIGHT LEFT TAIL LIGHT LIGHT SWITCH NCA WIRE PARK BRAKE SWITCH OIL PRESSURE SWITCH RADIO CLOCK RECEIVER REAR COMPT BLOWER RELAY REAR LID MODULE RIGHT LICENSE PLATE LIGHT RIGHT TAIL LIGHT STEERING ANGLE SENSOR STEERING COLUMN POSITION SWITCH TRUNK LID LOCKING SWITCH TRUNK LID RELEASE SWITCH (INTERIOR) TRUNK LID SWITCH UNDERHOOD LIGHT SWITCH UNLOADER RELAY TERMINAL 15 UNLOADER RELAY, TERMINAL R W/ 2000 LATE PROD, 2001 W/ 2000 EARLY PROD, 1999 W/ 1999 EARLY PROD WASHER FLUID LEVEL SWITCH

BLK WIRE BRN WIRE BRN/ORG WIRE CAMSHAFT SENSOR HALL EFFECT CAMSHAFT SENSOR HALL EFFECT 1 CAMSHAFT SENSOR HALL EFFECT 2 CYLINDER 1 IGNITION COIL CYLINDER 2 IGNITION COIL DATA LINK CONNECTOR E-BOX FAN ENGINE CONTROL MODULE (DME) ENGINE CONTROL MODULE I (DME) ENGINE CONTROL MODULE II (DME) HEATED OXYGEN SENSOR I SHIELD HEATED OXYGEN SENSOR II SHIELD HOT-FILM MASS AIR FLOW SENSOR 1 HOT-FILM MASS AIR FLOW SENSOR 2 IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 IGNITION COILS I SHIELD IGNITION COIL 5 IGNITION COIL 6 IGNITION COIL 7 IGNITION COIL 8 IGNITION COIL II SHIELD IGNITION COILS 1-4 SHIELD IGNITION COILS 5-8 SHIELD IGNITION COILS I SHIELD IGNITION COILS II SHIELD NCA WIRE OIL LEVEL SENSOR RESISTOR TERMINAL 15 UNLOADER RELAY THROTTLE POSITION CONTROL MODULE TRANS- MISSION CONTROL MODULE (AGS) TRANSMISSION CONTROL MODULE (AGS) UNLOADER RELAY TERMINAL 15

1999, 2000 RADIO/HIFI TOP HIFI 1999 LATE PROD, 2000, 2001 2000 LATE PROD, 2001 BASIC INTERFACE BRN WIRE BRN/BLK WIRE CASSETTE BOX LIGHT STEPTRONIC SWITCH CD CHANGER AMPLIFIER CHARGING SOCKET CLOSED- CIRCUIT CURRENT CUT-OFF RELAY ELECTRONIC SHOCK ABSORBER CONTROL MODULE DIVERSITY DSP SWITCH RADIO DWS CONTROL UNIT ELECTRONIC DRIVE AWAY PROTECTION CONTROL UNIT (EWS) GENERAL MODULE GLOBAL LOCKING SWITCH GLOVE BOX LIGHT SWITCH GPS RECEIVER HAZARD WARNING FLASHER SWITCH IGNITION SWITCH SEAT LOAD ASSEMBLY INTERFACE INTERIOR PROTECTION CONTROL MODULE LEFT "C" PILLAR) LIGHT MODULE MULTI-INFORMATION DISPLAY (MID) NCA WIRE OBDII PLUG ON BOARD MONITOR PASSENGER'S SEAT ADJUSTMENT REMOTE CONTROL SWITCH PASSENGER'S SEAT BELT SWITCH PASSENGER'S SEATBACK ADJUSTMENT SWITCH PROGRAM SWITCH RDC CONTROL MODULE REAR CIGAR LIGHTER REAR COMPT MONITOR REAR CIGAR LIGHTER REAR MULTI- INFORMATION DISPLAY (MID) SUN BLIND REMOTE CONTROL SWITCH SWITCHING CENTER TANDEM TELEPHONE TRANSCEIVER/ CHARGING ELECTRONICS TRANSMISSION RANGE INDICATOR LIGHT UNLOADER RELAY, TERMINAL R VIDEO INPUT COMPEN- SATOR VIDEO MODULE SEARCH BUTTON VISUAL ENTRY AID RELAY WIPER/ WASHER SWITCH
