BMW 7 series E38 facelift (1998-2001) rear headrest control module Wiring diagrams
This page contains all the electrical diagrams for the component. rear headrest control module, in which he is found in the car BMW 7 series E38 facelift (1998-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear headrest control module (1 of 2)
BRN WIRE
DRIVER'S MAKEUP MIRROR SWITCH FRONT INTERIOR/ READING LIGHT
ELECTRIC FAN
ELECTROCHROMIC REAR VIEW MIRROR
FUEL PUMP
GARAGE DOOR OPENER
HEADLIGHT WASHER PUMP
HIGH LEVEL STOP LIGHT
HYDRAULIC UNIT SUNROOF MODULE
INTENSIVE WASHER PUMP
LEFT REAR SEAT BELT SWITCH
LEFT REAR SEAT CONTROL HEAD- REST SWITCH
LEFT REAR SEAT HEATER
LEFT REAR SEAT HEATER RIGHT REAR SEAT HEATER
LEFT REAR SEAT HEATER SWITCH
LEFT REAR SEAT LUMBAR SUPPORT SWITCH
LEFT REAR SEAT LUMBAR SUPPORT VALVE BLOCK
LEFT REAR SEATBACK HEATER
PASSENGER'S MAKEUP MIRROR SWITCH
PASSENGER'S SEAT HEATER
REAR HEADREST CONTROL MODULE
RIGHT REAR FOOTWELL LIGHT
RIGHT REAR INTERIOR LIGHT
RIGHT REAR SEAT BELT SWITCH
RIGHT REAR SEAT CONTROL HEAD- REST SWITCH
RIGHT REAR SEAT CONTROL HEAD- REST SWITCH LEFT REAR SEAT LUMBAR SUPPORT SWITCH
RIGHT REAR SEAT HEATER
RIGHT REAR SEAT HEATER SWITCH
RIGHT REAR SEAT LUMBAR SUPPORT SWITCH
RIGHT REAR SEAT LUMBAR SUPPORT VALVE BLOCK
SECONDARY AIR INJECTION PUMP
TRAILER CONNECTOR
TRAILER MODULE (AHM)
WASHER PUMP
Go to component -> Ground distribution circuit (4 of 7) -> REAR HEADREST CONTROL MODULE
Wiring diagram rear headrest control module (2 of 2)
BKWD
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
FUSE
GRN/BLK/YEL WIRE
GRY WIRE
HOT AT ALL TIMES FUSE BOX (RIGHT SIDE OF LUGGAGE COMPT) FUSE
HOT IN ACCY, RUN, OR START
LEFT REAR HEADREST MOTOR
LEFT REAR SEAT BELT SWITCH
LEFT REAR SEAT CONTROL SWITCH/ HEADREST SWITCH
LEFT REAR SEATBACK MOTOR
REAR HEADREST CONTROL MODULE
RED/WHT WIRE
RIGHT REAR HEADREST MOTOR
RIGHT REAR SEAT BELT SWITCH
RIGHT REAR SEAT CONTROL SWITCH/ HEADREST SWITCH
RIGHT REAR SEATBACK MOTOR
VIO/WHT/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Rear power seat circuit -> REAR HEADREST CONTROL MODULE
